Owon DGE3000 Series User Manual

7.Specification
61
Burst Characteristics
Burst Characteristics
Waveform
Sine wave, square wave, ramp wave, pulse wave and arbitrary
wave (Except DC)
Types
N-cycle,Gated
N-cycle trigger
source
Internal, External, manual
Carrier frequency
2 mHz ≤ Offset ≤ Maximum frequency of corresponding carrier /2
N-cycle trigger cycle
DGE3032
67 ns ～ 500 s（Min = Cycles * Period）
DGE3062
34 ns ～ 500 s（Min = Cycles * Period）
periodicity
1 ～ 60000（Max =Burst Period / Period）/infinite
Gated source
External trigger
Counter Specifications
Counter Specifications
Measurement function
Frequency, period
Frequency Range
Single channel :100 mHz - 100 MHz
Frequency resolution
7 digits
Input resistance
1 MΩ
Input/Output Characteristics
Input/Output Characteristics
Communication Interface
USB Host, USB Device
External modulation input
Input frequency range
DC - 20 kHz
Input level range
± 1V full scale
Input impedance
10 kΩ (typical)
External trigger input
Level
TTL-compatible
Slope
Rising or falling (selectable)
Pulse Width
>100ns
Sync Output
Level
TTL-compatible
Maximum frequency
1MHz
General Specifications
Display
Display type
3.6-inch color LCD display
Display resolution
480 Horizontal ×272 Vertical pixels

Owon DGE3000 Series Specifications

General

Brand	Owon
Model	DGE3000 Series
Category	Portable Generator
Language	English
