Owon DGE3000 Series User Manual

7.Specification
57
DGE3062
Typical (0dBm)
DC to 1MHz: <-65dBc
1MHz to 35MHz: <-60dBc
35MHz to 60MHz: <-50dBc
Total harmonic
distortion
< 0.2 %, 10 Hz to 20 kHz, 1 Vpp
Non-harmonic
distortion
Typical (0dBm)
≤10MHz: <-70dBc
>10MHz: <-70dBc + 6dB/ sound interval
Phase noise
Typical (0dBm, 10kHz offset)
10MHz: ≤ -110dBc/Hz
Square
Rise/fall time
< 20ns
Jitter (rms), typical
(1Vpp, 50Ω)
200ps + 30ppm
Overshoot
< 5%
Ramp
Linearity
< 1% of peak output
(typical 1 kHz, 1 Vpp, symmetry 50%)
Symmetry
0% to 100%
Pulse
Period
DGE3032
67 ns to 500 s
DGE3062
50 ns to 500 s
Pulse Width
≥ 24ns
Rise and fall time
≥ 15ns
Overshoot
< 5%
Jitter (rms), typical
(1Vpp, 50Ω)
200ps + 30ppm
Noise
Types
Gaussian white noise
Bandwidth (-3dB)
20 M
Arbiratry wave
Bandwidth
10M
Waveform length
2 to 8K points
Sampling rate
DGE3032
125Ma/s
DGE3062
300Ma/s
Amplitude accuracy
14 bits
Modulation Characteristics
Modulation Characteristics
Modulation Type
AM, DSB-AM, FM, PM, ASK, FSK, PSK, BPSK, QPSK, 3FSK,
4FSK, OSK, PWM, SUM

Owon DGE3000 Series Specifications

General

Brand	Owon
Model	DGE3000 Series
Category	Portable Generator
Language	English
