7.Specification
55
7. Specification
All technical specifications are guaranteed when the following conditions are met, unless
otherwise stated.
The signal generator must be operated continuously for more than 30
minutes at the specified operating temperature (20°C to 30°C) to meet
these specifications
The signal generator is in the calibration internal and has performed a
self-calibration.
In addition to the specifications marked with the word "Typical", the
specifications used are guaranteed.
Waveforms
Waveforms
Bandwidth
DGE3032
30 MHz
DGE3062
60 MHz
Sample Rate
DGE3032
125MSa/s
DGE3062
300MSa/s
Vertical Resolution
14 bits
Channel
2
Standard
Waveforms
Sine wave, square wave, ramp wave, pulse wave, noise
Arbitrary
Waveforms
Sinc, exponential rise, exponential decline, electrocardiogram,
Gaussian, semi-positive, Lorentz, dual audio, DC voltage totaling
more than 150 kinds
Frequency Characteristics
Frequency Characteristics (Frequency resolution to 1 μHz)
Sine wave
DGE3032
2 mHz ~ 30MHz
DGE3062
2 mHz ~ 60MHz
Square wave
DGE3032
2 mHz ~ 15MHz
DGE3062
2 mHz ~ 20MHz
Pulse wave
DGE3032
2 mHz ~ 15MHz
DGE3062
2 mHz ~ 20MHz
Ramp wave
DGE3032
2 mHz ~ 1 MHz
DGE3062
2 mHz ~ 2 MHz
Noise wave (-3 dB)
20 MHz BWAWGN
Arbitrary wave
2 mHz - 10 MHz
Frequency
resolution
1 μHz or 7 significant figures
