To update your instrument firmware, do the following:
1. Push the Utility button,press the Syster softkey,press NextPage to next
page,press Upgrade ,the instrument weill have a prompt message.
2. Push the Ok button,the external disk icon is displayed on the PC .
3. Visit the company's website on the PC and select the required instrument
firmware upgrade package for the corresponding model. Download the
“ AG. upp “ file in the firmware upgrade package to the PC, and copy the
firmware to the external disk that is displayed.
4. Restart the device. After the device is powered on, the upgrade status is
displayed.
5. After the upgrade, the instrument will shut down automatically.
6. Press the
button to power on the instrument(Press Utility to check
whether the version is the desired target version)
Counter
The frequency counter measures signals in the frequency range from 100 mHz
to 200 MHz. The Counter connector on the rear panel is used by default to
receive the frequency counter input signal. The frequency meter works from
the start, unless the connector is set to an external clock input or clock output.
(1) Press the front panel Counter function key to enter the frequency counter
interface.
(2) Connect the signal to be tested to the Counter connector on the rear
panel.
(3) Press the HF Rejection softkey to toggle On or Off high frequency
rejection. High-frequency rejection can be used to filter high-frequency
factors when measuring low-frequency signals, improving measurement
accuracy. When measuring low frequency signals with a frequency less
than 1 kHz, turn on high frequency rejection to filter out high frequency
noise interference; turn off high frequency rejection when measuring high
frequency signals with frequencies greater than 1 kHz.
(4) The frequency, period and duty cycle can be viewed on the frequency
meter interface.
6. Troubleshooting
1. The screen is still black and there is no display after you press the
power switch, please follow the steps below:
⚫ Check whether the power is connected correctly.
To Next Page
