7.Specification
60
BPSK
Carrier
Sine wave, square wave, ramp wave, arbitrary wave
Modulated signal
source
Internal
Internal modulation
waveform
50% square wave
BPSK rate
2 mHz to 1MHz
Phase deviation range
0°～360°
Data source
01patt, 10 patt, PN15,PN21
QPSK
Carrier
Sine wave, square wave, ramp wave
Modulated signal
source
Internal
QPSK frequency
2 mHz to 1MHz
OSK
Carrier
Sine wave
Modulated signal
source
Internal
Internal modulation
waveform
50% square wave
Oscillation time
8ns to 499.75μs
OSK frequency
2 mHz to 1MHz
SUM
Carrier
Sine wave, square wave, ramp wave
Modulated signal
source
Internal or external
Internal amplitude
modulation frequency
2 mHz to 100kHz
Depth
0.0% to 100.0%
Sweep Characteristics
Sweep Characteristics
Carrier
Sine, square wave, ramp wave, arbitrary wave (Except DC)
Minimum/maximum
starting frequency
2mHz（minimum）/ maximum frequency of corresponding carrier
Minimum/maximum
termination
frequency
2mHz（minimum）/ maximum frequency of corresponding carrier
Types
Linear, logarithmic
Sweep time
1 ms to 500 s ± 0.1%
Trigger source
Internal, External, manual
