Press it repeatedly until the voltage offset is +-0.003V (+-3mV) off the expected value.
Once you have finished with all the points of the calibration curve, press C8 to save.
_______________________________________________
You have to repeat the process with all the CV outputs.
Every CV listens to a different MIDI channel, CV1 listens to MIDI Channel 1 and CV2, to the MIDI
channel 2 and so on, until CV8 in channel 8.
You can do it with any keyboard connected to the MIDI IN port, but we recommend doing it in your
DAW to better see the octave range.
If you are an Ableton user, you can download this project that will help you along this process.
