SECTION 1 GENERAL
vi
HOW TO... FRONT PANEL REFERENCE
This is a quick reference to commonly used FRONT PANEL functions and will aid the user in quickly
learning how to use functions of interest.
HOW TO SECTION
CALIBRATE OUTPUT AND METERS 8.2
CALIBRATE PROGRAMMABLE OUTPUT IMPEDANCE 4.6.3.1.1
CHANGE OPERATING MODES 4.1.1
CLOSE / OPEN OUTPUT CONTACTOR 4.1.2 steps 6,7
COPY A WAVEFORM 4.6.2.2
COPY A PROGRAM 4.6.1.1
CREATE A TIME BASED TRANSIENT 4.5.2.1
CREATE A CYCLE BASED TRANSIENT 4.5.2.2
CREATE A PROGRAM 4.5.1.1
DELETE A PROGRAM 4.6.1.2
EDIT A WAVEFORM 4.6.2.1
EDIT A PROGRAM 4.5.1
EDIT A TRANSIENT 4.5.2
ERASE ALL RAM AND RESET CPU 4.6.1.3
EXECUTE A PROGRAM 4.4.1
EXECUTE A TRANSIENT 4.4.2
QUICKLY PUT THE UNIT TO USE 4.1.2
READ HARMONIC SPECTRUM 4.3.1.1
READ OUTPUT POWER 4.3.1
READ OUTPUT POWER FACTOR 4.3.1
READ OUTPUT CURRENT CREST FACTOR 4.3.1
READ OUTPUT VOLTAGE 4.3.1
READ OUTPUT FREQUENCY (INDICATOR) 4.3.1
READ OUTPUT CURRENT 4.3.1
SELECT LOCAL or REMOTE OPERATION 5.1
SELECT METERING SENSE POINT (INTERNAL, EXTERNAL) 4.6.3.1
SET CSC (CONTINUOUS SELF CALIBRATION) 4.6.3.1
SET BAUD RATE FOR RS-232 SERIAL INTERFACE 10.3
SET GPIB DEVICE ADDRESS 4.6.3.3
SET MIN/MAX FREQUENCY RANGE 4.6.3.1
SET OUTPUT POWER FORM 4.5.1.1
SET OUTPUT CURRENT LIMIT 4.5.1.1
SET OUTPUT PHASE ANGLES 4.5.1.1
SET OUTPUT COUPLING (XFMR OR DIRECT) 4.5.1.1
SET OUTPUT FREQUENCY 4.1.2, 4.3.3, 4.5.1.1
SET FREQUENCY LIMITS 4.6.3.1
SET OUTPUT VOLTAGE 4.1.2, 4.3.2, 4.5.1.1
SET VOLTAGE LIMITS 4.6.3.1
SET OUTPUT WAVEFORM 4.5.1.1
SET PROGRAMMABLE OUTPUT IMPEDANCE 4.6.3.1
SET SLEW RATES 4.6.3.6
SET TRANSITION TIME 4.6.3.1
