SECTION 5 REMOTE OPERATION
98
5.6.2 IEEE-488.2 DEVICE CONTROL COMMANDS
The following lists the IEEE-488.2 Common Commands for Device Control of the UPC. Refer to the
ANSI/IEEE-488.2 1987 standard for more information.
*RST Command
: RESET. Initialize the UPC with the following parameters:
CSC OFF
CURRENT LIMIT CURRENT METERING RANGE
INITIAL VOLTAGE 0
KEYBOARD LOCK OFF
MAX FREQUENCY 1200 Hz.
MAX VOLTS 600 V
MIN FREQUENCY 15 Hz.
MIN VOLTS 0 V
MODE MANUAL
OUTPUT DISABLED
OUTPUT COUPLING DIRECT
OUTPUT FORM 1 or 3 (depending on model)
OUTPUT FREQUENCY 60 Hz.
OUTPUT VOLTAGE(S) 0
PHASE ANGLE B 120º
PHASE ANGLE C 240º
PROG.Zo OFF
RANGE CONTROL AUTO
SENSE INTERNAL
TRANSITION TIME 0
WAVEFORM ΦA 1
WAVEFORM ΦB 1
WAVEFORM ΦC 1
NOTE
: Stored programs are not erased. FREQUENCY SPAN is not changed.
*TST? Query
: Self test. Test validity of non-volatile RAM.
Returns 0 if no error.
*WAI Command
: Wait-to-continue. Only useful following the :PROG:EXEC:TRANS or
*TRG commands. All other commands are executed sequentially as the
Program Message is parsed.
*TRG Command
: IEEE-488.2 Device trigger function. Executes Transient Events (if
any), of currently executed program.
*LLO Command
: LOCAL LOCKOUT. Puts the UPC into REMOTE mode and
disables local operation of the UPC keyboard.
*GTL Command
: GOTO LOCAL. Enables local operation of the UPC keyboard.
*DCL Command
: DEVICE CLEAR. Performs a hardware RESET of the UPC.
