SECTION 3 INSTALLATION
23
3.5 INSTALL CABLING AND COVER
NOTE
: Most users will not need to concern themselves with the following installation issue if the UPC is
packaged with a power source.
• Connect J2A of the UPC to P2A of the SCU.
• Connect J3A of the UPC to P3A the LED PCB.
• Connect J3B of the SCU to P3B of the LED PCB.
• Attach J4 from the UPC to the rear panel of the SCU.
• Attach J5 from the UPC to the rear panel of the SCU.
• Connect J6A of the SCU to P6A of the UPC PCB.
• Place the top cover on top and install six screws.
3.6 CONNECT INPUT SERVICE
Verify the Input Power Circuit Breaker on the front panel is off. Connect the Input Line Cord to the back
of the SCU chassis. Verify the 115/230 volt switch on the rear panel is set to the correct position. Input
frequency may be 50 - 400 Hz.
CAUTION -
Use of equipment connected to improper input voltage
may cause permanent damage and void the warranty.
Turn the Input Circuit Breaker ON. Refer to section 4 to verify proper operation.
!
