SECTION 4 OPERATION
35
4.3 MANUAL MODE
This section describes operation in Manual Mode. In this mode you may slew or directly enter voltage or
frequency values. Parameters other than volts and frequency can only be changed by editing and
executing a steady-state Program.
The V/I METER display will indicate MANUAL MODE in the lower left corner of the display.
4.3.1 METERING DISPLAYS
There are three primary metering displays plus a set of optional Harmonic Analysis displays. Pressing
the DISPLAY key will cycle through the metering displays. If a display other than a metering display is
active, pressing the DISPLAY key will abort common edit functions and return to a metering display.
The V/I METER display indicates FREQuency, metering SENSE point (INTernal or EXTernal) and
MANUAL MODE or PROGRAM # executing. This display meters true RMS Voltage (line to neutral and
line to line) and true RMS current.
V/I METER: ENTRY: 120.0
FREQ=60.00 Va=120.0 Vb=120.0 Vc=120.0
SENSE=INT Vab=208.0 Vbc=208.0 Vca=208.0
MANUAL MODE Ia=00.00 Ib=00.00 Ic=00.00
The POWER METER display meters kVA, true kW and PF.
POWER METER: PHASE A PHASE B PHASE C
KVA 0.000 0.000 0.000
KW 0.000 0.000 0.000
PF 1.000 1.000 1.000
The AMPS METER display meters RMS amps, PEAK amps and CREST FACTOR.
AMPS METER: PHASE A PHASE B PHASE C
RMS 0.00 0.00 0.00
PEAK 0.00 0.00 0.00
CREST FACTOR 1.00 1.00 1.00
