Pacific Power Source UPC-3 User Manual

SECTION 1 GENERAL
vii
REMOTE INTERFACE FUNCTION REFERENCE
This is a quick reference to commonly used REMOTE INTERFACE functions and will aid the user in
quickly finding the functions of interest.
FUNCTION SECTION
CALIBRATE METERING
5.6
CALIBRATE PROGRAMMABLE OUTPUT IMPEDANCE 5.4.1
CLOSE / OPEN OUTPUT CONTACTOR 5.7.5, 5.4.2
CREATE A PROGRAM 5.3, 5.7.1
CREATE A TIME BASED TRANSIENT 5.3, 5.7.1
CREATE A CYCLE BASED TRANSIENT 5.3, 5.7.1
DELETE A PROGRAM 5.3.3
DOWNLOAD A METERED WAVEFORM - REMOTE INTERFACE 5.7.7
DOWNLOAD / UPLOAD A STORED WAVEFORM REMOTE INT. 5.4.3
ERASE ALL RAM AND RESET CPU 5.3.3
EXECUTE A PROGRAM 5.4.1, 5.7.3
EXECUTE A TRANSIENT 5.4.1, 5.7.4
READ HARMONIC SPECTRUM 5.5.2
READ OUTPUT POWER 5.5.2, 5.7.6
READ OUTPUT POWER FACTOR 5.5.2, 5.7.6
READ OUTPUT CURRENT CREST FACTOR 5.5.2, 5.7.6
READ OUTPUT VOLTAGE 5.5.2, 5.7.6
READ OUTPUT FREQUENCY (INDICATOR) 5.5.2, 5.7.6
READ OUTPUT CURRENT 5.5.2, 5.7.6
SELECT LOCAL or REMOTE OPERATION 5.1
SELECT METERING SENSE POINT (INTERNAL, EXTERNAL) 5.4.2
SET CSC (CONTINUOUS SELF CALIBRATION) 5.4.2
SET GPIB DEVICE ADDRESS 4.6.3.3
SET MIN/MAX FREQUENCY RANGE 5.4.1
SET OUTPUT POWER FORM 5.4.2
SET OUTPUT CURRENT LIMIT 5.4.1
SET OUTPUT PHASE ANGLES 5.4.1
SET OUTPUT COUPLING (XFMR OR DIRECT) 5.4.2
SET OUTPUT FREQUENCY 5.4.1
SET FREQUENCY LIMITS 5.4.1
SET OUTPUT VOLTAGE 5.4.1
SET VOLTAGE LIMITS 5.4.1
SET OUTPUT WAVEFORM 5.4.1
SET PROGRAMMABLE OUTPUT IMPEDANCE 5.4.1
SET TRANSITION TIME 5.4.1
