SECTION 5 REMOTE OPERATION
86
5.4.2 SIGNAL ROUTING
:[SOURce:]FORM <n> Sets Output power form.
n = <1>Single Φ, <2>Split Φ, or <3>Three Φ
:[SOURce:]COUPLing <s> Sets Output coupling.
s = <DIRECT> or <XFMR>
:[SOURce:]VOLTage:ALC[:STATE] <b> The ALC keyword controls CSC enable/disable.
b = <OFF> or <ON> or <0>OFF or<1>ON
:SENSe:PATH <s> Selects source location for metering and CSC.
s = <0>Internal or <1>External
:OUTPut[:STATE] <b> Command
: OUTPUT ENABLE. Opens or Closes the power source output
relay.
b = <OFF> or <0>, <ON> or <1>.
Query
: returns actual state of output relays, <0>OFF or <1>ON, not
the OUTPUT ENABLE value
NOTE
: Setting the OUTPUT POWER ON-AUTO/OFF switch (front
panel of the power source) to OFF, overrides the OUTPUT ENABLE
command.
5.4.3 WAVEFORM CONTROL
:PROGRAM:NAME <WFnn> selects waveform “nn” for loading or data query.
nn = 1 - 22 for data query or 2 - 22 for data defining (loading).
:PROGram:[SELected:]DEFine <data>
loads selected waveform (2-22) with data from the IEEE-488 Bus. The
number of data elements must be 1024, representing 0-359.7 degrees
in 0.3512º steps. Each element is a signed percentage of peak full
scale voltage and may have a maximum of 2 decimal digits. Each
element must be separated by a comma.
NOTE
: Only commas may separate the values, NO Carriage Returns
or Line Feeds may separate the values.
e.g., <0,+5.23,+10,-50,+20,+25.7,+30,-43.91,+100>
