SECTION 5 REMOTE OPERATION
85
5.4.1 OUTPUT PARAMETERS (cont)
:[SOURce:]RANGe <n> sets Output Range Control (for power sources with Range Control).
n = <0> to <4>. 0 sets the mode to AUTO. See 4.6.3.5
:[SOURce:]IMPEDance:STATE <b> Enables or disable
optional Programmable Output Impedance function.
b = <OFF>, <0> or <ON>, <1>
:[SOURce:]IMPEDance <z> sets the value of the optional Programmable Output Impedance.
z = varies based on the present configuration and operational mode of
the power source.
Use :SOUR:IMPED:LIM:MIN? and :SOUR:IMPED:LIM:MAX? to
determine the available range.
:[SOURce:]IMPEDance:LIMit:MINimum? <min z>
Query
: returns the minimum allowable impedance
:[SOURce:]IMPEDance:LIMit:MAXimum? <max z>
Query
: returns the maximum allowable impedance
:[SOURce:]IMPEDance:CAL <z1,z2,z3, x1,z4, x2,z5, x3,z6>
Calibrates the optional Programmable Output Impedance function with
values for:
Description x values z values
Direct Coupled 1Φ z1 Ω
Direct Coupled 2Φ z2 Ω
Direct Coupled 3Φ z3 Ω
XFMR Coupled - Ratio X x1:1 z4 Ω
XFMR Coupled - Ratio Y x2:1 z5 Ω
XFMR Coupled - Ratio Z x3:1 z6 Ω
x values are transformer ratios. Relation to unity (1) is assumed. For
a 2.5:1 step-up transformer, the x value is 2.5. For a 0.1:1 step-down
transformer, the x value is .1.
z values are the calibrated impedance value, expressed in ohms.
See para. 4.6.3.1.1 for details on this function.
:[SOURce:]IMPEDance:RESet Resets Programmable Output Impedance calibration values to the
system defaults.
:[SOURce:]TRANSient:AUTO <b> Sets Transient WFs auto RMS mode.
b = <OFF>, <0> or <ON>, <1>
See para. 4.6.3.8 for a detailed description.
