SECTION 4 OPERATION
57
4.6 SETUP MODE
SETUP MODE is used to:
• Copy and Delete Programs
• Copy, Edit, and Create Waveforms
• Set Min. and Max. Voltage Limits
• Set Min. and Max. Frequency Limits
• Engage and Disengage CSC (Continuous Self Calibration)
• Set the Metering Sense Point – Internal or External
• Set Slew rates
• Set Transition Time
• Set Transformer Ratio
• Change Frequency Span
• Enable keyboard lockout
• Set initial power on output voltage
• Monitor UPC and Power Source status
• View Firmware Version
• Enable Calibration Mode for Metering
• Set Serial Interface Parameters or GPIB Device Address
• Erase Memory
• Set Amps-to-Volts Current Metering Ratio
• Define Current Transformer Location
• Set Output Range - for power sources that support it
• Display and set the Number of Power Source Amplifiers
• Synthesize Waveforms from Harmonic values (Option)
• Calibrate Programmable output impedance (Option)
• Enable and Set Programmable Output Impedance (Option)
From any meter display, press the fn key to enter SETUP MODE.
SETUP: PRESS 1 PROGRAM
2 WAVEFORM
3 GENERAL SETUP
4 CALIBRATION
4.6.1 PROGRAM SETUP
PROGRAM SETUP is used to copy and delete programs and erase memory.
From any METER display (V/I, AMPS or POWER), press the fn key to enter SETUP MODE.
From the SETUP display, press 1 to enter PROGRAM SETUP.
PROGRAM SETUP: PRESS
1 TO COPY A PROGRAM,
2 TO DELETE A PROGRAM,
3 TO ERASE ALL MEMORY AND RESET CPU.
