Pacific Power Source UPC-3 User Manual

SECTION 5 REMOTE OPERATION
80
5.3 PROGRAM CONTROL
:PROGram:NAME <nn> Command
: selects program “nn” for executing, deleting or copying.
nn = <0> to <99>
Query: returns the program number last selected.
:PROGram[:SELected]:DEFine <program>
Command
: defines the values stored in program “nn”. Both steady-
state and transient segment parameter names and values may be
sent. Program parameters are defined in the following sections.
NOTE
: Only commas may separate the values, NO Carriage Returns
or Line Feeds may separate the values within a single Command.
Query
: returns steady-state values of selected program and segment
values of most recently selected segment. "LAST" is returned with
segment data if the segment is the last segment in the program.
STEADY-STATE OUTPUT PARAMETERS
FORM,<n>,
COUPLing,<s>,
XFMRRATIO,<n.nn>,
FREQuency,<n>,
VOLTage,<n>, see Convention #11.
VOLTage1,<n>,
VOLTage2,<n>,
VOLTage3,<n>,
CURRent:LIMit,<n>,
PHASe2,<n>,
PHASe3,<n>,
WAVEFORM,<n>, see Convention #11.
WAVEFORM1,<n>,
WAVEFORM2,<n>,
WAVEFORM3,<n>,
EVENTS,<n>,
TRANSIENT SEGMENT PARAMETERS
(OPTIONAL)
SEGment,<n>, Only 1 segment per Program Message may be sent.
FSEG,<n>,
VSEG,<n>, see Convention #11.
VSEG1,<n>,
VSEG2,<n>,
VSEG3,<n>,
WFSEG,<n> see Convention #11.
WFSEG1,<n>,
WFSEG2,<n>,
WFSEG3,<n>,
TSEG,<n>,
LAST Sent only if this is the LAST segment.
