SECTION 5 REMOTE OPERATION
89
5.5.2 METERED DATA QUERIES (cont)
:MEASure:PF1? Query
: metered power factor (KW/KVA) ΦA.
Returns <0> to <1.0>
:MEASure:PF2? Query
: metered power factor (KW/KVA) ΦB.
Returns <0> to <1.0>
:MEASure:PF3? Query
: metered power factor (KW/KVA) ΦC.
Returns <0> to <1.0>
:FETCh[:WAVEform]:VOLT1?
:FETCh[:WAVEform]:CURRent1? Query
: metered waveform data (line-to-neutral voltage only).
Use :VOLT1 for ΦA, :VOLT2 for ΦB, and :VOLT3 for ΦC volts
Use :CURR1 for ΦA, :CURR2 for ΦB, and :CURR3 for ΦC current
Returns a string of NR2 type numbers, comma delimited. Only a
single waveform may be queried in a command.
:MEASure:SPECTrum:VOLT1[:MAGnitude]? (option: Harmonic Analysis and Synthesis)
[:ABSolute]?
:MEASure:SPECTrum:CURRent1[:MAGnitude]?
[ABSolute]? Query
: waveform harmonic magnitudes
Use :VOLT1 for ΦA, :VOLT2 for ΦB, and :VOLT3 for ΦC volts
Use :CURR1 for ΦA, :CURR2 for ΦB, and :CURR3 for ΦC current
Returns a data set of 51, NR2 type numbers, comma delimited. The
1
st
element is the magnitude of the fundamental, for reference. The 2
nd
element is the 2
nd
harmonic, etc. The accuracy of harmonics may be
limited by the FREQUENCY SPAN setting.
See para. 4.3.1.1 and 5.4.1.
:MAG returns each magnitude as a percent of the fundamental.
:ABS returns absolute magnitude
:MEASure:SPECTrum:PHASe? (option: Harmonic Analysis and Synthesis)
Query
: phase angles in degrees for the most recent harmonics data
Returns a data set of 51, NR2 type numbers, comma delimited. The
1
st
element is the angle of the fundamental, for reference. The 2
nd
element is the angle of the 2
nd
harmonic, etc. The previous
:MEASure:SPECTrum:parameter command defines which phase
angles are sent. If parameter was VOLT1 then the phase angles will
be for VOLT1.
:MEASure:SPECTrum:THD? (option: Harmonic Analysis and Synthesis)
Query
: Returns Total Harmonic Distortion of the most recent
:MEASure:SPECTrum:parameter command, as above.
:MEASure:SPECTrum:OHD? (option: Harmonic Analysis and Synthesis)
Query
: Returns Odd Harmonic Distortion of the most recent
:MEASure:SPECTrum:parameter command, as above.
:MEASure:SPECTrum:EHD? (option: Harmonic Analysis and Synthesis)
Query
: Returns Even Harmonic Distortion of the most recent
:MEASure:SPECTrum:parameter command, as above.
