SECTION 4 OPERATION
47
4.5.1.1 PROGRAM EXAMPLE (cont)
Press 108, ENTER, 108, ENTER, 108, ENTER, to select 108 volts line to neutral on all three phases.
PROGRAM: #4 FORM=3 COUPLING=DIRECT
FREQ=400 Va=108 Vb=108 Vc=108
WFa=1 WFb=1 WFc=1
#SEGS=0 Ilim=50 PHb=120º PHc=240º
Press 1, ENTER, 1, ENTER, 1, ENTER, to select Waveform 1 on all three phases.
PROGRAM: #4 FORM=3 COUPLING=DIRECT
FREQ=400 Va=108 Vb=108 Vc=108
WFa=1 WFb=1 WFc=1
#SEGS=0 Ilim=50 PHb=120º PHc=240º
Press ENTER to select default maximum Ilim for this Power Source.
PROGRAM: #4 FORM=3 COUPLING=DIRECT
FREQ=400 Va=108 Vb=108 Vc=108
WFa=1 WFb=1 WFc=1
#SEGS=0 Ilim=50 PHb=120º PHc=240º
Press 120, ENTER, 240, ENTER, to select 120º phase shift for phase B and 240º phase shift for phase
C referenced to phase A.
PROGRAM: #4 FORM=3 COUPLING=DIRECT
FREQ=400 Va=108 Vb=108 Vc=108
WFa=1 WFb=1 WFc=1
#SEGS=0 Ilim=50 PHb=120º PHc=240
Press EXECUTE to execute this new program. The V/I METER display will become active.
V/I METER:
FREQ=400.0 Va=108.0 Vb=108.0 Vc=108.0
SENSE=INT Vab=187.1 Vbc=187.1 Vca=187.1
PROGRAM #4 Ia=00.0 Ib=00.0 Ic=00.0
