SECTION 4 OPERATION

4.6.2.1 EDIT WAVEFORM (cont)

Press 2, ENTER, to select waveform 2.

EDIT WAVEFORM: NUMBER=2 RANGE=2-22

STARTING PHASE ANGLE =0 0-359.9º

ENDING PHASE ANGLE =0 0-359.9º

VOLTAGE IN PERCENT =100 (+/-)0-100%

Press 85, ENTER, to select the start angle.

EDIT WAVEFORM: NUMBER=2 RANGE=2-22

STARTING PHASE ANGLE =85 0-359.9º

ENDING PHASE ANGLE =0 0-359.9º

VOLTAGE IN PERCENT =100 (+/-)0-100%

Press 95, ENTER, to select the end angle.

EDIT WAVEFORM: NUMBER=2 RANGE=2-22

STARTING PHASE ANGLE =85 0-359.9º

ENDING PHASE ANGLE =95 0-359.9º

VOLTAGE IN PERCENT =100 (+/-)0-100%

Press 100, to select the voltage (% of full scale) between the starting and ending phase angles.

EDIT WAVEFORM: NUMBER=2 RANGE=2-22

STARTING PHASE ANGLE =85 0-359.9º

ENDING PHASE ANGLE =95 0-359.9º

VOLTAGE IN PERCENT =100 (+/-)0-100%

Press EXECUTE to save the new waveform.

This will cause the UPC to temporarily stop producing any output signal while the new waveform data is

being calculated internally in the UPC.

After entering the VOLTAGE IN PERCENT data, pressing EDIT will automatically step the display to the

next available waveform phase angle section. The screen data will begin with the previously entered

ENDING PHASE ANGLE and will show the VOLTAGE IN PERCENT of the existing waveform at that

point. This simplifies editing of sequential portions of a waveform.

Define and Execute a program using Waveform 2. The waveform should appear as shown in figure

4.6.2.1.

Pacific Power Source UPC-3 User Manual
