SECTION 4 OPERATION
70
4.6.3.2 FREQUENCY SPAN
FREQUENCY SPAN sets the available frequency range and resolution of the output waveform and the
number of samples per cycle used for metering data.
From any METER display (V/I, AMPS or POWER), press the fn key to enter SETUP MODE.
From the SETUP display, press 3 to enter GENERAL SETUP.
From the GENERAL SETUP 1 display, press 2 to enter FREQUENCY SPAN.
FREQUENCY SPAN: PRESS 1 FOR 150 Hz
SPAN=600Hz 2 FOR 300 Hz
3 FOR 600 Hz
4 FOR 1200 Hz
PRESS
FREQUENCY SPAN WAVEFORM STEPS METERING
SAMPLES
1 15.00 – 150 Hz. 1024 512
2 15.00 – 300 Hz. 512 256
3 (default) 15.00 – 600 Hz. 256 128
4 15.00 – 1200 Hz. 128 64
4.6.3.3 UPC STATUS
UPC STATUS indicates firmware version, RS-232 SERIAL or GPIB interface status, and other system
settings. It also allows the user to set the GPIB device address. See section 10 if the RS-232 SERIAL
REMOTE INTERFACE is installed. The UPC SETUP menu is accessed from the General Setup menu
(fn,3,1).
From any METER display (V/I, AMPS or POWER), press the fn key to enter SETUP MODE.
From the SETUP display, press 3 to enter GENERAL SETUP.
From the GENERAL SETUP 1 display, press 3 to enter UPC STATUS.
If your UPC is configured with a serial port interface the UPC STATUS screen is:
UPC STATUS: FIRMWARE 141916 v4.25
BAUD 19200. PARITY:NONE LAST BYTE=00h
TRANSFORMER RATIO 2.00 PAs=3
AMPS:VOLTS RATIO 4.00A=1 V PRI EOS=CR/LF
For systems equipped with a GPIB (IEEE-488) communication port, the display will be:
UPC STATUS: FIRMWARE 141916 v4.25
GPIB ADDRESS 1 IFC LAST DATA BYTE=00h
TRANSFORMER RATIO 2.00 PAs=3
AMPS:VOLTS RATIO 4.00A=1 V PRI
