Digital Video Recorder
11
Layout Button
Pressing the
LAYOUT button toggles between different display formats. The available formats are: 3x3, 1+7, 1+5,
2x2 and PIP.
Zoom Button
Pressing the
ZOOM button zooms the current image on the screen. A PIP with a rectangle temporarily displays showing
what area of the screen has been enlarged. You can use the arrow buttons to move the rectangle to another area.
PTZ Button
Pressing the
PTZ button enters the PTZ (Pan/Tilt/Zoom) mode which allows you to control properly configured cameras.
Ente
Button
The
(Enter) button selects a highlighted item or completes an entry that you have made during system setup. This
button is also used to enter the Cameo mode in the Live Monitoring mode or Search mode.
Alarm Button
Pressing the
ALARM button resets the DVR’s outputs including the internal buzzer during an alarm.
PTZ Control Button
While in the PTZ mode, the
PRESET buttons are used to save Presets and load a Preset View, the ZOOM buttons are
used to Zoom In and Zoom Out, and the FOCUS buttons are used for Near Focus and Far Focus.
Backup Button
Pressing the
BACK UP button allows you to copy video clips.
Calenda
Button
In the search mode, pressing the
CALENDAR button displays the Calendar Search screen.
Turning on the Power
Connecting the power cord to the DVR turns on the unit. The unit takes approximately 50 seconds to initialize.
Initial Unit Setup
Before using your DVR for the first time, you will want to establish the initial settings. This includes items such as
time and date, display language, camera, remote control, record mode, network and password. Your DVR can be set
up using various screens and dialog boxes.
Throughout the screens you will see
. Highlighting the and pressing the button gives you the opportunity
to reset that screen to its default settings.
Highlighting This page or All pages and pressing the
button resets the current
page or all pages of the screen to its or their default settings.
