Digital Video Recorder
51
You can define the screen layout in a variety of formats and set the DVR to sequence through the different screen layouts
(pages) so that all the cameras will be displayed. You can also set up the DVR to display one camera or a group of
cameras all the time while cycling through the remaining cameras in a “cameo” window. This can be done with one
camera displayed full screen while displaying the cameo window as a PIP (picture in picture), or displaying the cameras
in a grid pattern with the bottom right window as the cameo.
NOTE: Sequence cannot be used in the 3x3 and 1+7 modes of the 8-channel DVR, and 2x2 mode of the 4-channel
DVR.
You can adjust the display dwell time by highlighting the box beside Interval and pressing the button. You can
select dwell intervals ranging from 1 second to 1 minute.
Highlight Event Monitoring On and press the button. Pressing the button toggles between On and Off.
When it is On, the DVR will display the camera associated with the event when an event occurs.
Highlight the box beside Resolution and press the button. You can select from 1280x1024, 1440x900 and
1920x1080 for NTSC video, and 1280x1024, 1440x900 and 1920x1080 (@ 60Hz or 50Hz) for PAL video.
NOTE: When the individual main monitors are connected to the HDMI and VGA connectors for simultaneous
operation, it is recommended to use monitors supported with the same resolution. If monitors unsupported
with the same resolution are connected, video cannot be displayed on the monitor with the resolution
you have set.
Highlight Fit To Screen and press the button. Pressing the button toggles between On and Off. When it
is On, the DVR will resize video to fit the main monitor screen.
