Digital Video Recorder
V1.0
83
CONNECTORS
Video Input Composite: 4 or 8 BNC
Monitor Output
HDMI: 1 HDMI
VGA: 1 VGA
Audio In 4 RCA connector
Audio Out 1 RCA connector
Alarm Input/Output Terminal Blocks
Ethernet Port RJ-45
RS232 Serial Port Two-connector terminal block
RS485 Serial Port Two-connector terminal block
IR Port 1 Remote Control
USB Port 2 (USB 2.0)
STORAGE
Primary Storage SATA hard disk drive
Secondary Storage USB hard disk drive or flash drive
GENERAL
Dimensions (W x H x D) 10.4" x 2.0" x 7.5" (265mm x 52mm x 191mm)
Unit Weight 3.3 lbs. (1.48kg)
Shipping Weight 6.0 lbs. (2.73kg)
Shipping Dimensions
(W x H x D)
14.0" x 4.1" x 13.4" (355mm x 103mm x 340mm)
Operating Temperature 41°F to 104°F (5°C to 40°C)
Operating Humidity 0% to 90%
Power 12V , 2A (Adaptor: 100-240V~, 50/60Hz, 1.5A, 12V , 5A)
Power Consumption Max. 25W
Approvals FCC, CE
Specifications are subject to change without notice.
