2. Input/output signal settings
2-1-9. Displaying the input image information
[10.5] Input Menu/DVI-IN
Size
[10.5] Input Menu/DVI-IN
H-Freq
[10.5] Input Menu/DVI-IN
V-Freq
[10.5] Input Menu/DVI-IN
Dot Clock
These are used to display the information concerning the DVI-D input signal images.
The information cannot be changed.
Size:
This indicates the pixel count of the images.
H-Freq:
This indicates the horizontal frequency of the images.
V-Freq:
This indicates the vertical frequency of the images.
Dot Clock:
This indicates the dot clock frequency of the images.
The formats supported are listed below.
<DVI-D formats supported>
Input video signal
Dot clock frequency
(MHz)
Frequency
Horizontal
(kHz)
Vertical
(Hz)
XGA
1024  768
Digital 65.0 48.36 60.00
WXGA
1280  768
Digital 79.5 47.78 59.87
SXGA
1280  1024
Digital 108.0 63.98 60.02
WSXGA+
1680  1050
Digital 148.3 65.29 59.95
WUXGA
1920  1200
Digital 154.0 74.04 59.95
UXGA
1600  1200
Digital 162.0 75.00 60.00
1080/50p
1920  1080
Digital (RGB) 148.5 56.25 50.00
1080/59.94p
1920  1080
Digital (RGB) 148.5/1.001 67.50/1.001 60.00/1.001
 If the format of the input signals is not supported, it may not be possible to import the signals properly, and a black image or
disturbed image may appear.
