7. Function for linking up with the remote camera controller
7-2-4. Displaying the camera icon
When signals from the remote camera selected using the
AW-RP50 are supplied to the unit, the “
” camera icon can
be displayed on the multi view display.
The camera icon is displayed in front of the name of the
material which is displayed on the split screen.
[Settings established at the unit]
Set the input signal status to “On” (display) by operating
the menu item below.
[8] MultiView Out/Frame Menu
6. Input Status
[Settings established at the AW-RP50]
Set the remote cameras which will correspond with the
unit’s image inputs.
(On the AW-RP50, SDI IN 1 to 4 are displayed as
INPUT1 to 4 while DVI-IN is displayed as INPUT5.)
When a remote camera has been selected by the
AW-RP50, the function (CAMSEL) for sending the
selection information is enabled.
7-2-5. Operating the unit’s parameters
from the AW-RP50
The unit’s settings can be changed by operating the
PAN/TILT lever and ZOOM button on the AW-RP50.
[Settings established at the AW-RP50]
Set what is to be targeted by the PAN/TILT lever and
ZOOM button operations in the switcher (SW).
[Unit’s menu items which can be operated]
When the following submenus are displayed on the unit,
the PAN/TILT lever and ZOOM button on the AW-RP50
operations take effect.
[3] PinP Menu
The PinP position can be changed using the PAN/TILT
lever, and the PinP size can be changed using the
ZOOM button.
[6] ChromaKey Menu
While the chroma key marker is displayed, the chroma
key marker position can be changed using the
PAN/TILT lever, and the chroma key marker size can
be changed using the ZOOM button.
[2] WIPE Menu
The wipe start position can be changed using the
PAN/TILT lever.
7-2-6. Sending and receiving the tally
information
The information of the ON AIR tally sent by the unit over the
network can be received by the AW-RP50.
[Settings established at the AW-RP50]
Set the remote cameras that correspond to the unit’s
image input.
(On the AW-RP50, SDI IN 1 to 4 are displayed as
INPUT1 to 4 while DVI-IN is displayed as INPUT5.)
Enable the function used to receive the information of
the ON AIR tally sent by the unit over the network.
