43 (E)
4. System settings
4-2-2. Other settings
[13] Operation Menu
4. Key Priority
Refer to “1-3. KEY”.
[13] Operation Menu
5. Bus Mode
Refer to “1-1-4. Selecting the bus mode”.
[13] Operation Menu
6. Time Unit
Refer to “1-1-7. Auto transition”.
[13] Operation Menu
7. Slide Lever
Refer to “1-1-6. Manual transitions”.
[13] Operation Menu
8. GPI Input
This is used to enable or disable control from the GPI input
port.
Enable: Control is enabled.
Disable: Control is disabled.
For details on what is controlled, refer to
“5-2. TALLY/GPI”.
[13] Operation Menu
9. GPI Output
This is used to enable or disable control from the GPI output
port.
Enable: Control is enabled.
Disable: Control is disabled.
For details on what is controlled, refer to
“5-2. TALLY/GPI”.
[13] Operation Menu
10. CamCont Link
This is used to set the link function with the AW-RP50 to ON
or OFF.
On: Link function is set to ON.
Off: Link function is set to OFF.
Refer to “7. Function for linking up with the remote
camera controller”.
[13] Operation Menu
11. SYSTEM Menu
When “Locked” is selected as this item’s setting, it is not
possible to change the [14] SYSTEM Menu settings.
Select this setting when it is not desirable for the
[14] SYSTEM Menu settings to be changed easily.
