2. Input/output signal settings
2-2. Setting the output signals
Signals can be output from the three connectors:
SDI OUT 1, SDI OUT 2 and DVI-D OUT.
The output signals are set on the [11] Output Menu of the
OSD menu.
5&+176 2)/
5&+176 289
&8+176 #7:
5&+176.KOKV 1HH
&8+1765K\G #WVQ
&8+1765ECNG (KV8
&8+176/XFGV 
=?1WVRWV/GPW
2-2-1. Assigning the output signals
[11] Output Menu
1. SDI-OUT1
[11] Output Menu
2. SDI-OUT2
[11] Output Menu
3. DVI-OUT
The following assignment options are available.
PGM This is the main line output of the switcher.
Images with wipe, mix, key, PinP or other effects
added are output.
PVW The PVW images which enable the next
operation to be checked are output.
CLN Clean signals (images resulting when the key and
PinP effects have been removed from the PGM
signal) are output.
AUX The signal selected using the AUX bus is output.
MV The multi view display signal is output.
KEY OUT The key signal is output.
The multi view display frames are not displayed in what
is output from the SDI OUT 1 connector (SDI-OUT1).
Note
2-2-2. Setting the colour areas
[11] Output Menu
4. SDI-OUT:Limit
This is used to set the colour area for the SDI output signal
images.
Off The colour area is not subject to any limitations.
108 The amplitude level of each of the colours (R, G, B) is
limited to between 0 % and 108 %.
104 The amplitude level of each of the colours (R, G, B) is
limited to between 0 % and 104 %.
100 The amplitude level of each of the colours (R, G, B) is
limited to between 0 % and 100 %.
2-2-3. Setting the DVI-D output signals
The following setting is selected for DVI-D output signal
images.
[11] Output Menu
5. DVI-OUT:Size
This is used to set the resolution to be output.
The following resolutions are supported.
Supported resolutions
Auto Using the DVI signals, the information of the
device at the output destination is gathered,
and the images are output at the optimum
resolution.
 The vertical frequency is set to 60 Hz, and
the maximum resolution is WUXGA.
XGA
1024  768
WXGA
1280  768
SXGA
1280  1024
WSXGA+
1680  1050
UXGA
1600  1200
WUXGA
1920  1200
1080/59.94p
1920  1080
1080/50p
1920  1080
