62 (E)
ENGLISH
No. Sub menu Setting item Setting
13 Operation Menu 1 OSD OUT Setting range SDI-OUT2, DVI-OUT, SDI-OUT2+DVI-OUT
Initial value SDI-OUT2+DVI-OUT
2 OSD Size Setting range FULL, Upper-Left, Upper-Right, Lower-Right, Lower-Left
Initial value FULL
3 OSD Back Setting range On, Off
Initial value On
4 Key Priority Setting range PinP over KEY, KEY over PinP
Initial value PinP over KEY
5 Bus Mode Setting range A/B, PGM(A)/PST(B), PGM(B)/PST(A)
Initial value PGM(A)/PST(B)
6 Time Unit Setting range Sec, Frame
Initial value Sec
7 Slide Lever Setting range BKGD, KEY, PinP, NoAsign
Initial value BKGD
8 GPI Input Setting range Enable, Disable
Initial value Enable
9 GPI Output Setting range Enable, Disable
Initial value Enable
10 CamCont Link Setting range On, Off
Initial value Off
11 SYSTEM Menu Setting range Unlocked, Locked
Initial value Unlocked
14 SYSTEM Menu 1 Format
Setting range
1080/59.94i, 1080/50i, 1080/24PsF, 1080/23.98PsF, 720/59.94p,
720/50p, 480/59.94i, 576/50i
Initial value 1080/59.94i
2 HiResMV Setting range On, Off
Initial value Off
3 16:9SQ Setting range On, Off
Initial value Off
4 AUX Anci Setting range On, Off
Initial value Off
5 PGM Anci Setting range On, Off
Initial value Off
6 PVW Anci Setting range On, Off
Initial value Off
7 MV Anci Setting range PGM, PVW, Off
Initial value Off
8 Initial Setting range Yes, No
Initial value No
9 IP Address Setting range —
Initial value 192.168.0.8
10 Subnet Mask Setting range —
Initial value 255.255.255.0
11 Gateway Setting range —
Initial value 192.168.0.1
15 SYSTEM Status SYSTEM Ver.
Display only
..
SOFT Ver.

GLUE FPGA Ver.

MAIN FPGA Ver.

FONT Ver.

MAC Address
−−−−−
FAN Alarm, NoAlarm
Power Alarm, NoAlarm
Temperature Alarm, NoAlarm
Table of menu items
