Chapter 8 Reading Reports/Lists
Reading Transaction Journal
Items in the transaction journal are listed below.
No. Item Explanation
(1) Printout date The date at which the Transaction Journal printed
(2) Printout time Printout time
(3) Journal number Journal number
(4) Communication result “OK” indicates that the communication was successful.
“Busy” indicates that the communication has failed because of busy line.
“Stop” indicates that the Stop key was pressed during communication.
“JUNK” indicates that the communication was canceled.
“P-OK” indicates that memory overflow occurred while storing the
documents into the memory for transmission but successfully
stored document(s) was sent.
“R-OK” indicates that the Relayed XMT was successful.
“B-OK” indicates that the Batch transmission was successful.
“M-OK” indicates that the Memory reception/Substitute reception was
successful.
“- -” indicates LAN transmission.
“3-digit Info Code”
indicates that the communication has failed.
Refer to Information Codes (see page 215).
(1)
(2)
*************** -Journal- ************************* Date MMM-dd-yyyy ***** Time 15:00 * * * P.01
(3) (4) (5) (6) (7) (8) (9) (10) (11) (12)
No. Comm. Pages File Duration X/R Identification Date Time
Diagnostic
001 OK 001/002 149 00:00:52 XMT 215
MMM-dd
20:04 C8444B0577000000
002 -- 001/001 151 00:00:02 XMT TEST MMM-dd
20:07 001 STN(S)LAN
003 -- 003/003 153 00:00:20 XMT fax@nwfax1 MMM-dd
20:09 001 STN(S)LAN
004 OK 003/003 154 00:00:21 RCV fax@nwfax1.rdmg.mgcs MMM-dd
20:10 LAN
005 OK 001 155 00:00:19 XMT 215 MMM-dd
20:11 C0542B0577000000
006 634 000/003 156 00:00:00 XMT
215
MMM-dd
20:14 0800420000000000
007 408 *003 00:02:14
XMT 215
MMM-dd
21:17 0040440A30080000
008 JUNK 000 157 00:00:00 RCV 01234567890
MMM-dd
21:19 C800000000000000
049 OK 000/001 159 00:00:07 XMT TEL XMT
MMM-dd
20:14 0800420000000000
050 OK 001/001 160 00:00:16 XMT TEL XMT
MMM-dd
20:19 CB444BG577000000
<< Continue >>
