FPΣ User's Manual
6.4 Input and Output Wiring
83
Open collector output type
NPN output PNP output
Vcc
0V
+
1
2
3
4
COM
Vcc
0V
+
1
2
3
4
COM
A
Sensor
2
Output
B
FPΣ
3
Power supply for input
1
Internal circuit
4
Input terminal
Voltage output (universal output) type
Vcc
0V
+
COM
1
2
3
4
+
A
Sensor
2
Output
B
FPΣ
3
Power supply for input
1
Internal circuit
4
Input terminal
Two-wire output type
+
COM
1
2
3
4
A
Sensor
2
Output
B
FPΣ
3
Power supply for input
1
Internal circuit
4
Input terminal
