Appendix
FPΣ User's Manual
288
FPG-C24R2(H)TM
EXPANSION
CONNECTOR
(10)
+20
-10
150
(3.5)
60.0
90.0
30.0
60.0
90.0
(5.0)
(4.5)
CPU with communication cassette
For dimensions, refer to the transistor output type CPU (see page
286).
12.4.3 Expansion Unit
FPG-XY64D2T/FPG-XY64D2P
(18)
60.0
90.0
(3.5)
(4.5)
