FPΣ User's Manual
2.2 Unit Types
9
2.2 Unit Types
The following units are available for the FPΣ:
2.2.1 CPU
Number of I/O points
Name
Input Output
Product no.
NPN 16 FPG-C32T2H-A
Transistor
PNP 12 FPG-C28P2H-A
FPΣ CPU
Relay 8 FPG-C24R2H-A
NPN 16 FPG-C32T2HTM
Transistor
PNP 12 FPG-C28P2HTM
FPΣ CPU with
thermistor input
16
Relay 8 FPG-C24R2HTM
2.2.2 FPΣ Expansion Units
Number of I/O points
Name
Input Outpeut
Product no. Manual
NPN FPG-XY64D2T
FPΣ I/O expansion
unit
32
PNP
32
FPG-XY64D2P
This manual
1 axis FPG-PP11
Transistor
2 axes FPG-PP21
1 axis FPG-PP12
FPΣ positioning unit
Line driver
2 axes FPG-PP22
ARCT1F365
2 axes FPG-PN2AN
4 axes FPG-PN4AN
FPΣ positioning unit
RTEX
8 axes FPG-PN8AN
ARCT1F421
FPΣ memory
expansion unit
256 Kwords FPG-EM1 This manual
FPΣ S-Link master
unit
128 inputs/outputs using S-Link FPG-SL ARCT1F403
2.2.3 Communication Cassettes
A detachable communication cassette (optional) should be used when using functions such
as MEWTOCOL-COM Master/Slave, program controlled communication, PLC Link, or
Modbus RTU.
Name Description Product no.
FPΣ communication cassette –
1-channel RS232C type
1-channel unit with a 5-wire RS232C port
RS/CS control is possible.
FPG-COM1
FPΣ communication cassette –
2-channel RS232C type
2-channel unit with two 3-wire RS232C ports
Communication with two external devices is possible.
FPG-COM2
