High-Speed Counter and Pulse Output
FPΣ User's Manual
144
Y4
Y3
XB
X5
X3
X5
X3
FPΣ
0V (24V DC)
B
A
C
(-) (+)
XB
Home return start
X5
Home input
X3
Near home input
Y3
CW pulse output
Y4
CCW pulse output
A
Motor driver
B
Stepping motor
(+)
+ side
C
Moving table
(-)
- side
X3
Near home sensor
X5
Home sensor
Pulse output diagram
250ms 250ms
1000Hz
120Hz
0Hz

1
Positioning start
2
Near home input
3
Home input
