1. Setting the communication parameters (see "Setting Communication Parameters" on
page
188)
2. Generating the data in the send buffer
To generate the data in the send buffer, define a variable in the program and copy the data to
the send buffer using a transfer instruction, e.g. F10_BKMV.
The storage area for the data to be sent starts with the second word of the send buffer (offset
1). Offset 0 contains the number of bytes to be sent.
1
Storage area for the number of bytes to be sent
0
1
2
n
Offset
2


1
3
4
2n 2n-1
2
Storage area for the data to be sent
Bold numbers indicate the order of transmission.
The maximum volume of data that can be sent is 2048 bytes.

EXAMPLE
Define a send buffer for 30 bytes (ARRAY [0...15] OF WORD) and copy 8 characters of a
string ("ABCDEFGH") into the buffer.
Send buffer layout:
0
1
2
4
16#42(B) 16#41(A)
16#44(D) 16#43(C)
16#48(H) 16#47(G)
16#46(F) 16#45(E)
8
3
Offset
15
The first word of the send buffer (offset 0) is reserved for the number of bytes to be sent.
Therefore, copy the data into offset 1 (SendBuffer[1]).
When sending begins (the execution condition for F159_MTRN turns to TRUE), the value in
offset 0 is set to 8. At the end of transmission, the value in offset 0 is automatically reset to 0.
The data in offset 1 to offset 4 is sent in order from the low order byte.
