FPΣ User's Manual
8.6 Program Controlled Communication
215
A
B
1
2
3
5
4
6
7
8
9
0
a b c
FP...
FPΣ
System register settings:
In order to use the data in the receive buffer, define a global variable having the same starting
address and capacity. In this example, the starting address is 200 (VAR_GLOBAL
awReceived) and the receive buffer capacity is 9 (ARRAY [0..8] OF WORD).
GVL
