7.7 [5-5] External Sensor
Settings related to external sensors can be programmed.
To assign destinations for sensor calls easily, click Destination Setting (see 2.1.6 Extension Number
Setting)
External Sensor No.
Indicates the number of the external sensor (reference only).
Value Range
For KX-TDA30:
1–4
For KX-TDA100/KX-TDA200
:
1–16
KX-TDA600:
1–64
Maintenance Console Location
7.7 [5-5] External Sensor
Programming Manual References
None
Feature Guide References
1.17.9 External Sensor
Physical Location—Shelf (KX-TDA600 only)
Indicates the shelf position (reference only).
Value Range
Shelf number
Maintenance Console Location
7.7 [5-5] External Sensor
Programming Manual References
None
Feature Guide References
1.17.9 External Sensor
