Panasonic KX-TG5631S

5 DISASSEMBLY INSTRUCTIONS
5.1. Base Unit
Shown in Fig.- To Remove - Remove -
1 Cabinet Cover Screws (2.6 × 12).....(A) × 4
Main P. C. Board Tapes, Solders and Cable
Main P. C. Board
2 Operational P. C. Board Tape
Screws (2.6 × 8).......(B) × 4
Operational P. C. Board
21
KX-TG5631S / KX-TG5632M / KX-TG5633B / KX-TGA560S / KX-TGA560M / KX-TGA560B
