Panasonic KX-TG5631S

5.2. Handset
Shown in Fig.- To Remove - Remove -
3 Cabinet Cover Screws (2 × 14)........(C) × 2
4 Follow the procedure.
5 Main P. C. Board Tape and Solders
Screws (2 × 9).............(D) × 3
Main P. C. Board
22
KX-TG5631S / KX-TG5632M / KX-TG5633B / KX-TGA560S / KX-TGA560M / KX-TGA560B
