Panasonic KX-TG5631S

Ref.
No.
Part No. Part Name & Description Remarks
Q142 B1BBAP000021 TRANSISTOR(SI)
Q161 2SD0874AS TRANSISTOR(SI)
Q171 2SD1819A TRANSISTOR(SI)
Q300 B1CHND000004 TRANSISTOR(SI)
Q340 2SD1819A TRANSISTOR(SI)
Q361 2SB1218A TRANSISTOR(SI)
Q362 2SD1819A TRANSISTOR(SI)
Q535 2SD1819A TRANSISTOR(SI)
(DIODES)
D101 PQVDMD5S DIODE(SI)
D113 MA111 DIODE(SI) S
D133 MA111 DIODE(SI) S
D142 PQVDRLZ20A DIODE(SI) S
D300 B0JCME000035 DIODE(SI)
D301 B0JCME000035 DIODE(SI)
D361 MA8220 DIODE(SI) S
D362 B0ECKM000008 DIODE(SI)
D472 MAZ805100L DIODE(SI)
D473 MAZ805100L DIODE(SI)
(COILS)
L101 PQLQXF330K COIL S
L102 PQLQXF330K COIL S
L300 G1C220M00037 COIL S
L361 G1C6R8MA0072 COIL
L472 G1C6R8MA0072 COIL
L473 G1C6R8MA0072 COIL
L501 PQLQR2KA213 COIL S
L711 MQLRF18NJFB COIL
L782 G1C1R0KA0096 COIL
L871 MQLRF3N3DFB COIL
C723 MQLRF2N7DFB COIL
(JACKS AND CONNECTOR)
CN101 K2LB102B0053 JACK
CN301 PQJJ1B4Y JACK S
CN661 K1MY32BA0026 CONNECTOR
(LCR FILTERS)
FL811 J0E5797B0001 LCR FILTER
FL821 KNCFH165R8Z1 LCR FILTER
FL881 J0E5797B0002 LCR FILTER
FL891 J0E5797B0002 LCR FILTER
(COMPONENTS PARTS)
RA500 D1H810440003 RESISTOR ARRAY
RA501 D1H84724A013 RESISTOR ARRAY S
(VARISTORS)
SA101 J0LE00000047 VARISTOR (SURGE ABSORBER)
SA104 J0LE00000047 VARISTOR (SURGE ABSORBER)
(RESISTORS)
R111 ERJ3GEYJ104 100K
R112 ERJ3GEYJ104 100K
R113 ERJ3GEYJ103 10K
R114 ERJ3GEYJ473 47K
R121 ERJ3GEYJ394 390K
R122 ERJ3GEYJ394 390K
R131 ERJ3GEYJ106 10M
R133 ERJ3GEYJ105 1M
R134 ERJ3GEYJ102 1K
R141 ERJ3GEYJ104 100K
R142 ERJ3GEYJ103 10K
R143 ERJ3GEYJ103 10K
R145 ERJ2GEJ103 10K
R151 ERJ3GEYJ106 10M
R152 ERJ3GEYJ395 3.9M
R154 ERJ3GEYJ102 1K
R160 ERJ3GEYJ751 750
R162 ERJ3GEYJ393 39K
R163 ERJ12YJ330 33
R164 ERJ3GEYJ470 47
R165 ERJ3GEYJ561 560
R167 ERJ2GEJ102 1K
R168 ERJ3GEY0R00 0
R171 ERJ2GEJ220 22
R172 ERJ2GEJ104 100K
R175 ERJ3GEYJ561 560
Ref.
No.
Part No. Part Name & Description Remarks
R176 ERJ2GEJ101 100
R178 ERJ2GEJ102 1K
R183 ERJ2GEJ222 2.2K
R185 ERJ3GEYJ333 33K
R303 ERJ3GEYJ221 220
R304 ERJ3GEYJ221 220
R308 ERJ3GEYJ121 120
R340 ERJ3GEYJ123 12K
R341 ERJ3GEYJ102 1K
R342 ERJ3GEYJ473 47K
R361 ERJ3GEYJ332 3.3K
R362 ERJ3GEYJ473 47K
R364 ERJ3GEYJ103 10K
R365 ERJ3GEYJ102 1K
R371 ERJ1TYJ680 68
R372 ERJ1TYJ680 68
R373 ERJ1TYJ680 68
R421 ERJ2GEJ473 47K
R422 ERJ2GEJ102 1K
R423 ERJ2GEJ102 1K
R453 ERJ2GEJ222 2.2K
R454 ERJ2GEJ222 2.2K
R459 ERJ2GEJ272 2.7K
R460 ERJ2GEJ272 2.7K
R472 ERJ2GEJ1R0 1
R473 ERJ2GEJ1R0 1
R517 ERJ2GEJ100 10
R533 ERJ2GEJ472X 4.7K
R535 ERJ2GEJ102 1K
R536 ERJ2GEJ222 2.2K
R537 ERJ3GEYJ102 1K
R538 ERJ2GEJ472X 4.7K
R673 ERJ2GEJ821 820
R675 ERJ2GEJ821 820
R679 ERJ2GEJ821 820
R701 ERJ2RKF103X 10K
R732 ERJ2GEJ100 10
R733 ERJ2GEJ100 10
R735 ERJ2GEJ4R7 4.7
R742 ERJ2GEJ331 330
R744 ERJ2GEJ102 1K
R747 ERJ2GEJ102 1K
R751 ERJ2GEJ102 1K
R752 ERJ2GEJ102 1K
R809 ERJ2GEJ561 560
R813 ERJ2GE0R00 0
R822 ERJ2GEJ271 270
R823 ERJ2GEJ180 18
R824 ERJ2GEJ271 270
R832 ERJ2GEJ562X 5.6K
R834 ERJ2GEJ332 3.3K
R865 ERJ2GEJ271 270
(CAPACITORS)
C101 F1K2J681A006 680P
C102 F1K2J681A006 680P
C111 F1J2A473A024 0.047
C112 F1J2A473A024 0.047
C113 PQCUV1A684KB 0.68
C120 ECUV1H102KBV 0.001
C121 ECUV1H681JCV 680P S
C122 ECUV1H681JCV 680P S
C132 ECUV1H103KBV 0.01
C142 ECUV1H103KBV 0.01
C152 ECUV1H103KBV 0.01
C161 EEE1EA100WR 10
C162 ECUV1H101JCV 100P
C163 ECUV1H472KBV 0.0047
C165 ECUV1C473KBV 0.047
C166 EEE1CA100SR 10
C167 ECUV1A224KBV 0.22
C172 F1G1H272A571 0.0027
C176 EEE0JA220SR 22
C178 ECUE1A333KBQ 0.033
97
KX-TG5631S / KX-TG5632M / KX-TG5633B / KX-TGA560S / KX-TGA560M / KX-TGA560B
