Panasonic Lumix DMC-FZ2000 User Manual

45
2. Getting Started/Basic Operations
Pressing the cursor button:
Selection of items or setting of values etc., is performed.
Pressing [MENU/SET]:
Confirmation of setting contents, etc., is performed.
• These operating instructions expresses the up, down, left, and
right of the cursor button as 3/4/2/1.
Press [DISP.] to switch the information displayed on the
screen.
• If the information on the screen is not displayed any longer
because no operation was performed for some time, press the
[DISP.] button or touch the screen to display the information
again.
Switching the display method of the viewfinder/monitor
Cursor buttons/[MENU/SET] button
• By assigning [Cursor Button Lock] to a function button, you can disable the cursor buttons and
the [MENU/SET] button. (P55)
[DISP.] button (Switching the displayed information)
In Recording Mode
> [Custom] > [LVF Disp.Style]
> [Custom] > [Monitor Disp. Style]
[ ] (viewfinder style): Scales down images slightly so that you can better review
the composition of the images.
[ ] (monitor style): Scales images to fill the entire screen so that you can see
their details.
MENU
MENU

Panasonic Lumix DMC-FZ2000 Specifications

General

Sensor	1-inch High Sensitivity MOS Sensor
Resolution	20.1MP
Aperture	f/2.8-4.5
ISO Range	ISO 125-12800 (expandable to ISO 80-25600)
Image Stabilization	5-Axis Hybrid O.I.S.
Max Shutter Speed	1/4000 sec
Built-in Flash	Yes
External Flash	Yes, via hot shoe
Storage Media	SD/SDHC/SDXC Memory Card
Video Recording	4K UHD at 30p/24p, Full HD at 60p
Viewfinder	2, 360k-dot OLED Live View Finder
Screen	3.0-inch 1, 040k-dot Free-Angle Touch LCD
Connectivity	Wi-Fi, USB 2.0, HDMI
Battery Life	Approx. 350 shots (CIPA)
Weight	966 g with battery and SD card
Dimensions	137.6 x 101.9 x 134.7 mm (5.42 x 4.01 x 5.30 inch)
