10. Recording Videos
DVQX1961 (ENG)
121
[Video Frame Marker]
A frame with the set aspect ratio is displayed on the recording screen. This
allows you to see during recording the angle of view that will be achieved
with trimming (cropping) in post-processing.
¨ [ ] ¨ [ ] ¨ Select [Video Frame Marker]
Colour bars/Test Tone
The colour bars are displayed on the recording screen.
A test tone is output while the colour bars are being displayed.
¨ [ ] ¨ [ ] ¨ Select [Color Bars]
Settings: [SMPTE]/[EBU]/[ARIB]
0
To end the display, press .
Adjusting the Test Tone
Rotate , or to select the test tone level.
0
There are 4 levels ([j12dB], [j18dB], [j20dB], and [MUTE]) of test tone to select.
[ON] Displays video grid lines on the recording screen.
[OFF] —
[SET]
[Frame
Aspect]
Sets the aspect ratio of video grid lines.
[2.39:1]/[2.35:1]/[2.00:1]/[1.85:1]/[16:9]/[4:3]/[1:1]/[4:5]
[Frame Color] Sets the colour of video grid lines.
[Frame Mask]
Sets the opacity of the outside of video grid lines.
[100%]/[75%]/[50%]/[25%]/[OFF]
0 The colour bars and test tone will be recorded on the video if video recording
is started while the colour bars are being displayed.
