12. Connections with External Devices (Video)
DVQX1961 (ENG)
140
Images Output via HDMI
The images output via HDMI differ depending on the recording mode.
[ ] Mode
Resolution, frame rate
Resolution and frame rate output is according to the following menu combinations:
– [Rec Quality] in the [Video] ([Image Format]) menu.
– [Down Convert] in [HDMI Rec Output] in the [Custom] ([IN/OUT]) menu
0 6K, 5.9K, and 5.4K videos are output with a 4K or FHD resolution. Output is not
possible during recording.
0 Anamorphic (4:3) video is output with a 4K or FHD resolution.
0 When set to a recording quality for high frame rate video, the frame rate is down-
converted for output.
[iA]/[P]/[S]/[M] Mode
Output is the same as [ ] mode during video recording or when [Video-
Priority Display] is set to [ON].
Output is with a 16:9 aspect ratio during recording standby. Resolution,
frame rate, YUV, and bit value output matches the connected device.
Aspect ratio, resolution, and frame rate output is according to the [Rec
Quality] settings in the [Video] ([Image Format]) menu. Resolution and
frame rate can be down-converted for output according to the application.
YUV 4:2:2 is used for YUV
and bit value output, as
shown on the right.
Recording to card HDMI output
4:2:2 10-bit 4:2:2 10-bit
4:2:0 10-bit 4:2:2 10-bit
4:2:0 8-bit 4:2:2 8-bit
0 When set to a 4:3 or 3:2 [Rec Quality], bands are added to the images and
they are output with a 16:9 aspect ratio.
0 Output may be in 8-bit if you output to devices that do not support 10-bit.
0 Refer to the “Operating Instructions” (PDF format) for details about the content
output for each combination of [Rec Quality] and [Down Convert].
0 When set to any [Aspect Ratio] other than 16:9, bands are added to the
images and they are output with a 16:9 aspect ratio.
