Panasonic Lumix S1H Series User Manual

12. Connections with External Devices (Video)
DVQX1961 (ENG)
145

Setting the Sound Pickup Range (DMW-MS2: Optional)
When using the Stereo Shotgun Microphone (DMW-MS2: optional), you
can set the microphone sound pickup range.
1
Select [Special Mic.].
0
¨ [ ] ¨ [ ] ¨ [Special Mic.]
2
(When [MANUAL] is selected)
Press 21 to adjust the sound pickup range and then press or
.

Reduction of Wind Noise
This reduces wind noise when an external microphone is connected.
¨ [ ] ¨ [ ] ¨ Select [Wind Cut]
Settings: [HIGH]/[STANDARD]/[LOW]/[OFF]
[STEREO] Picks up sound over a wide area.
[LENS AUTO]
Picks up sound from a range automatically set by the lens
angle of view.
[SHOTGUN]
Helps prevent picking up background noise, and records
sound from a specific direction.
[S.SHOTGUN]
Narrows the sound pickup range more than with
[SHOTGUN].
[MANUAL] Sets the range manually for sound pickup.
0 While the external microphone is connected, [ ] is displayed on the
screen.
0 When an external microphone is connected, [Sound Rec Level Disp.]
automatically turns [ON], and the recording level is displayed on the screen.
0 When [Mute Sound Input] is set to [ON], the audio input from the external
microphone is muted.
0 If noises are recorded when using the AC adaptor, use the battery.
0 When a Stereo Microphone (VW-VMS10: optional) is used, [Special Mic.] is
fixed to [STEREO].
0 Setting [Wind Cut] may alter the usual sound quality.
0 For details, refer to the operating instructions for the external microphone.
DC-S1HGN-DVQX1961_eng.book 145 ページ ２０１９年８月８日 木曜日 午後５時５５分

Panasonic Lumix S1H Series Specifications

General

Sensor Type	CMOS
Resolution	24.2MP
Camera Type	Mirrorless
Shutter Speed	1/8000 to 60 sec, Bulb
Video Recording Format	MOV, MP4
Monitor Type	Tilting touchscreen LCD
Lens Mount	L-Mount
Dimensions	151 x 114 x 110 mm
ISO Sensitivity	ISO 100-51200 (expandable to ISO 50-204800)
Video Recording	6K/24p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
Viewfinder	5.76 million-dot OLED electronic viewfinder
LCD Screen	3.2-inch 2.33M-dot touchscreen
Autofocus System	Contrast Detection with 225-area DFD
Connectivity	Wi-Fi, Bluetooth, HDMI, USB-C
Battery Life	Approx. 400 shots (CIPA standard)
Sensor Size	35.6 x 23.8 mm
Continuous Shooting	Up to 9 fps
Memory Card Slots	Dual SD card slots (UHS-II)
Battery	DMW-BLJ31
Weight	Approx. 1052g (with battery and SD card)
Log Profiles	V-Log
Storage Media	SD/SDHC/SDXC
Weather Sealing	Yes, splash and dust resistant
