Panasonic Lumix S1H Series

1. Introduction
DVQX1961 (ENG)
19
4
3
2
1
6
7
15
16
5
8
9
12
13
14
10
11
1
Dioptre adjustment dial (l 48)
2 Operation lock lever (l 48)
3
[(] (Playback) button (l 149)
4
Monitor (l 22, 185)/
Touch screen (l 47)
5 Rear tally lamp (l 89)
6
[ ] (AF mode) button (l 63)
7
[AF ON] button (l 63)
8 Focus mode lever (l 44, 63, 69)
9
Joystick (l 47)/
Fn buttons (l 153)
Centre: Fn8, 3: Fn9, 1: Fn10,
4:Fn11, 2: Fn12
10
[Q] (Quick menu) button (l 52)
11
Cursor buttons (l 46)/
Fn buttons (l 153)
3: Fn13, 1: Fn14, 4: Fn15,
2: Fn16
12
Control dial (l 46)
13
[MENU/SET] button (l 46, 54)
14
[ ] (Cancel) button (l 56)
15
[ ] (Delete) button (l 152)
16
[DISP.] button (l 50)
0 The following buttons light when the camera on/off switch is set to [ ].
The lighting timing can be changed in [Illuminated Button] in the [Custom]
([Operation]) menu.
–[(] button/[Q] button/[ ] button/[ ] button/[DISP.] button
