Supplement
Motor type
MAMA100W to 750W
MSMD 50W to 750W
MQMA100W to 400W


MSMA1.0kW, 1.5kW
MDMA1.0kW, 1.5kW
MHMA0.5kW to 1.5kW
MGMA900W

MSMA2.0kW
MDMA2.0kW



MSMA3.0kW to 5.0kW
MDMA3.0kW to 5.0kW
MHMA2.0kW to 5.0kW
MGMA2.0kW to 4.5kW

MFMA0.4kW, 1.5kW




MFMA2.5kW, 4.5kW
Fig.No.

Fig.2-1
Fig.2-2
Fig.2-3
Fig.3-1
Fig.5-1
Fig.2-4
Fig.2-5
Fig.2-5
Fig.3-2
Fig.4-1
Fig.2-4
Fig.2-5
Fig.2-5
Fig.3-3
Fig.4-2
Fig.2-4
Fig.2-5
Fig.2-5
Fig.3-4
Fig.4-3
Fig.2-4
Fig.2-5
Fig.2-5
Fig.3-5
Fig.4-1
Fig.2-4
Fig.2-5
Fig.2-5
Fig.3-6
Fig.4-3
 Type of junction cable
Part No of junction cable 
Encoder 17bit, 7-wire With battery holder for absolute encoder MFECA0**0EAE

Without battery holder for absolute encoder  MFECA0**0EAD
 2500P/r, 5-wire MFECA0**0EAM
Motor MFMCA0**0EED
Brake MFMCB0**0GET
Encoder 17bit, 7-wire With battery holder for absolute encoder MFECA0**0ESE

Without battery holder for absolute encoder MFECA0**0ESD
 2500P/r, 5-wire MFECA0**0ESD
Motor without Brake MFMCD0**2ECD
 Brake MFMCA0**2FCD
Encoder 17bit, 7-wire With battery holder for absolute encoder MFECA0**0ESE

Without battery holder for absolute encoder  MFECA0**0ESD
 2500P/r, 5-wire MFECA0**0ESD
Motor without Brake MFMCD0**2ECT
 Brake MFMCA0**2FCT
Encoder 17bit, 7-wire With battery holder for absolute encoder MFECA0**0ESE

Without battery holder for absolute encoder  MFECA0**0ESD
 2500P/r, 5-wire MFECA0**0ESD
Motor without Brake MFMCA0**3ECT
 Brake MFMCA0**3FCT
Encoder 17bit, 7-wire With battery holder for absolute encoder MFECA0**0ESE

Without battery holder for absolute encoder  MFECA0**0ESD
 2500P/r, 5-wire MFECA0**0ESD
Motor without Brake MFMCA0**2ECD
 Brake MFMCA0**2FCD
Encoder 17bit, 7-wire With battery holder for absolute encoder MFECA0**0ESE

Without battery holder for absolute encoder  MFECA0**0ESD
 2500P/r, 5-wire MFECA0**0ESD
Motor without Brake MFMCD0**3ECT
 Brake MFMCA0**3FCT
Table for junction cable by model of MINAS A4P series
