There are two monitoring methods, Polling and Trap
Polling Method
Trap Method
Polling Method
The SNMP Manager sends request messages to collect the status of KX-NS1000, and then KX-NS1000
sends response to the SNMP Manager.
Trap Method
KX-NS1000 sends information when a status change occurs or an alarm is detected.
• Up to 2 SNMP managers can be assigned.
• This PBX supports SNMP Protocol Version 1.0 and SNMP Version 2c.
• This PBX can only receive read-only MIBs. Write MIBs are not supported.
• This PBX supports MIB II.
3.2 SNMP Agent (1)
SNMP Agent Features
NS1000 includes SNMP features. It is possible for a PC assigned as an SNMP manager to manage and
receive PBX system status information, such as alarm information and general system activity using
S N M P.
Management Information Bases (MIBs) are sent to a PC (i.e., the SNMP manager) connected to the PBX
over a LAN and can then be stored and analyzed using SNMP manager software.
SNMP
Manager
