17.5. S-P.C.Board
S-P.C.Board TNPA3938
(Foil Side)
S-P.C.Board TNPA3938
(Component Side)
ADDRESS INFORMATION
IC
IC9001
IC9002
IC9003
IC9004
IC9005
S-P.C.Board
(Component Side)
C-6
D-7
D-7
D-8
D-7
