Panasonic SA-PM31PC - Electrical Part List

23.3.2. Cabinet Parts List
Ref.
No.
Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 L6FALEFH0023 DC FAN [M]
2 REEV0026 21P FFC (DECK PCB) [M]
3 REEV0039 17P FFC (CR16-MAIN) [M]
4 REEV0070 17P FFC (PANEL-MAIN) [M]
5 REEX0166 14P FFC WIRE [M]
6 RKMV0044-S FRONT PANEL [M]
7 RGKV0090-S LEFT STRIP ORNAMENT [M]
8 RGKV0091-S RIGHT STRIP ORNAMENT [M]
9 RFKLAPM31PCS CD LID ASS’Y [M]
10 RGLV0046 AC IN LIGHTING TIP [M]
11 RGLV0047 SSEQ LIGHTING TIP [M]
12 RFKHAPM31PCS REAR CABINET ASS’Y [M]PC
12 RKSV0024-H REAR CABINET [M]P
13 RGU2280-S CASS EJECT BUTTON [M]
14 RGUV0112-S FUNCTION BUTTON [M]
15 RGUV0110-S CD SELECTION BUTTON [M]
16 RGUV0111-S POWER BUTTON [M]
17 RGUV0114-S MAIN CONTROL BUTTON [M]
18 RGUV0115-S MP3 BUTTON [M]
19 RGWV0035-S VOLUME KNOB [M]
20 RHD26046-L SCREW [M]
21 RHD26049 SCREW [M]
22 RHD30007-1SJ SCREW [M]
23 RHGV0008 LEG CUSHION [M]
Ref.
No.
Part No. Part Name & Description Remarks
PRINTED CIRCUIT BOARD
REPV0016B DECK P.C.B. / TAPE EJECT
P.C.B.
[M]
(RTL)
REPV0037A MAIN P.C.B./ MAIN CONTROL
P.C.B. / POWER-IN P.C.B. /
PANEL P.C.B. / FUNCTION
P.C.B. /
[M]
(RTL)
REPV0038A POWER P.C.B. / TRANSFORMER
P.C.B.
[M]
(RTL)
REPX0321H DECK MECHANISM P.C.B. [M]
(RTL)
REP3569A CD LOADING P.C.B. [M]
(RTL)
REPV0039A CD SERVO P.C.B. [M]
(RTL)
INTEGRATED CIRCUITS
IC11 C0GAG0000007 IC DRIVER [M]
IC21 C0GAG0000007 IC DRIVER [M]
IC300 C1BB00000757 IC ASP [M]
IC302 C2CBJG000574 IC MICRO PROCESSOR [M]
IC305 C0DBZGC00067 IC 3.3V REGULATOR [M]
IC500 RSN315H41-P IC HIC [M]
IC501 C0AABB000125 IC OP AMP [M]
IC600 C0HBB0000044 IC FL DRIVER [M]
IC702 MN6627953HB IC LSI [M]
IC703 BA5948FPE2 IC 4 CH DRIVE [M]
IC971 CNB13030R2AU PHOTO INTERUPTOR [M]
IC1000 C1AA00000612 IC ANALOG SW [M]
IC1001 AN7326K IC DECK R/P [M]
TRANSISTORS
Q1 B3NAA0000068 TRANSISTOR [M]
Q200 KRA102STA TRANSISTOR [M]
Q201 B1ABCE000016 TRANSISTOR [M]
Q222 B1ABCE000016 TRANSISTOR [M]
Q223 B1ABCE000016 TRANSISTOR [M]
Q224 B1ABCE000016 TRANSISTOR [M]
Ref.
No.
Part No. Part Name & Description Remarks
24 RKF0688-S CASS HOLDER/LID [M]
25 RKMV0045-S TOP CABINET [M]
26 RKMV0046-S SIDE PANEL LEFT [M]
27 RKMV0047-S SIDE PANEL RIGHT [M]
28 RMB0448-J LOCK ROD SPRING [M]
29 RMB0780 CASS OPEN SPRING [M]
30 RMB0783 CD LID OPEN SPRING [M]
31 RMK0595 BOTTOM CHASSIS [M]
32 RMKV0037 INNER CHASSIS [M]
33 RMM0163-1 CASSETTE LOCK ROD [M]
34 RMN0780 CD LID SUPPORT [M]
35 RMNV0014 FL HOLDER [M]
36 RMNV0053 SSEQ LED COVER [M]
37 RMY0260 HEAT SINK (SMALL) [M]
38 RSC0669 SP EARTH R [M]
39 RSCV0052 REAR SHIELD PLATE [M]
40 RSCV0054 FL REAR SHIELD [M]
41 RUS757ZAA CASS HALF SPRING [M]
42 RXGX0003 DAMPER GEAR UNIT [M]
43 RXXV0037 HEAT SINK UNIT [M]
44 XTB3+10JFJK SCREW [M]
45 XTB3+8JFJK SCREW [M]
46 XTV3+10GFJ-M SCREW [M]
47 XTW3+15TFJ SCREW [M]
48 XTWS3+6TFJ SCREW [M]
49 RGPV0066-Q FL WINDOW [M]
50 RGKV0088-K CENTER ORNAMENT [M]
51 RKWV0045 SENSOR ORNAMENT [M]
Ref.
No.
Part No. Part Name & Description Remarks
Q301 KTA1504GRTA TRANSISTOR [M]
Q302 KRC102STA TRANSISTOR [M]
Q303 KTA1504GRTA TRANSISTOR [M]
Q304 B1GBCFGG0001 TRANSISTOR [M]
Q305 B1GBCFGG0001 TRANSISTOR [M]
Q306 KRC103STA TRANSISTOR [M]
Q307 B1ABCE000016 TRANSISTOR [M]
Q308 B1ABCE000016 TRANSISTOR [M]
Q309 KRC101STA TRANSISTOR [M]
Q310 KRC101STA TRANSISTOR [M]
Q400 KRA102STA TRANSISTOR [M]
Q422 B1ABCE000016 TRANSISTOR [M]
Q423 B1ABCE000016 TRANSISTOR [M]
Q424 B1ABCE000016 TRANSISTOR [M]
Q501 B1BACG000023 TRANSISTOR [M]
Q502 B1BCCG000002 TRANSISTOR [M]
Q505 B1ACCF000063 TRANSISTOR [M]
Q506 B1BCCG000002 TRANSISTOR [M]
Q508 KTC3199GRTA TRANSISTOR [M]
Q509 KRA110MTA TRANSISTOR [M]
Q514 2SD0592ARA TRANSISTOR [M]
Q515 KTC3199GRTA TRANSISTOR [M]
Q516 KTC3199GRTA TRANSISTOR [M]
Q517 KTC32030YTA TRANSISTOR [M]
Q519 B1AAGC000006 TRANSISTOR [M]
Q520 B1BACG000023 TRANSISTOR [M]
Q575 B1AAGC000006 TRANSISTOR [M]
Q577 2SC3940ARA TRANSISTOR [M]
Q578 KRC102MTA TRANSISTOR [M]
Q579 2SB0621AHA TRANSISTOR [M]
Q600 KRC119STA TRANSISTOR [M]
Q700 B1AACF000063 TRANSISTOR [M]
Q701 B1ADCF000001 TRANSISTOR [M]
Q701 KTA12710YTA TRANSISTOR [M]
Q702 B1AACF000063 TRANSISTOR [M]
Q703 B1AACF000063 TRANSISTOR [M]
Q704 KRA102MTA TRANSISTOR [M]
Q710 B1AAGC000006 TRANSISTOR [M]
Q711 B1AAGC000006 TRANSISTOR [M]
Q714 KTC3199GRTA TRANSISTOR [M]
