Panasonic SA-PM31PC - Page 115

Ref.
No.
Part No. Part Name & Description Remarks
Q715 KTC3199GRTA TRANSISTOR [M]
Q716 KTC3199GRTA TRANSISTOR [M]
Q717 KTC3199GRTA TRANSISTOR [M]
Q718 B1AAGC000006 TRANSISTOR [M]
Q719 B1AAGC000006 TRANSISTOR [M]
Q720 KTC3199GRTA TRANSISTOR [M]
Q721 KTC3199GRTA TRANSISTOR [M]
Q725 B1AAGC000006 TRANSISTOR [M]
Q726 B1AAGC000006 TRANSISTOR [M]
Q1101 B1ABGC000005 TRANSISTOR [M]
Q1201 B1ABGC000005 TRANSISTOR [M]
Q1302 B1GDCFJJ0002 TRANSISTOR [M]
Q1303 B1GBCFGH0001 TRANSISTOR [M]
Q1304 B1GDCFGH0002 TRANSISTOR [M]
Q1309 B1AAGC000006 TRANSISTOR [M]
Q1310 B1AAGC000006 TRANSISTOR [M]
Q1312 B1ABCF000011 TRANSISTOR [M]
Q1314 B1GDCFGH0002 TRANSISTOR [M]
Q1315 KTA12710YTA TRANSISTOR [M]
Q1316 2SD09650RA TRANSISTOR [M]
Q1317 B1ABGC000005 TRANSISTOR [M]
DIODES
D201 B0BC01000014 DIODE [M]
D302 B0ACCE000003 DIODE [M]
D303 B0ACCE000003 DIODE [M]
D304 MA729TX DIODE [M]
D305 B0ACCK000005 DIODE [M]
D500 B0FBAM000009 DIODE [M]
D505 B0AACK000004 DIODE [M]
D508 MTZJ15BTA DIODE [M]
D515 B0BA9R600002 DIODE [M]
D517 B0BA5R600016 DIODE [M]
D520 B0BA9R600002 DIODE [M]
D524 B0BA01100004 DIODE [M]
D525 B0AACK000004 DIODE [M]
D526 B0AACK000004 DIODE [M]
D530 B0AACK000004 DIODE [M]
D531 B0BA8R200005 DIODE [M]
D578 B0EAKM000117 DIODE [M]
D579 B0EAKM000117 DIODE [M]
D580 B0EAKM000117 DIODE [M]
D581 B0EAKM000117 DIODE [M]
D582 B0BA6R600008 DIODE [M]
D584 B0EAKM000117 DIODE [M]
D585 B0EAKM000117 DIODE [M]
D586 B0EAKM000117 DIODE [M]
D587 B0EAKM000117 DIODE [M]
D588 B0EAKM000117 DIODE [M]
D589 B0EAKM000117 DIODE [M]
D592 B0EAKM000117 DIODE [M]
D593 B0EAKM000117 DIODE [M]
D594 B0BA03000015 DIODE [M]
D600 B0BC6R700006 DIODE [M]
D601 B3ADA0000087 DIODE [M]
D609 B3AAA0000487 DIODE [M]
D700 B0AACK000004 DIODE [M]
D701 B0AACK000004 DIODE [M]
D702 B0AACK000004 DIODE [M]
D703 B0AACK000004 DIODE [M]
D704 B0AACK000004 DIODE [M]
D705 B0AACK000004 DIODE [M]
D706 B0AACK000004 DIODE [M]
D707 B0AACK000004 DIODE [M]
D708 MA2C16500E DIODE [M]
D709 MA2C16500E DIODE [M]
D750 MAZ80560ML DIODE [M]
D971 MA2C16500E DIODE [M]
D1301 B0ACCK000005 DIODE [M]
VARIABLE RESISTORS
Ref.
No.
Part No. Part Name & Description Remarks
VR600 EVEJ1CF3024B VOL. ENCORDER [M]
SWITCHES
S1 K0L1BA000065 STOCK SWITCH [M]
S2 K0L1BA000065 PLAY SWITCH [M]
S3 K0L1BA000078 BOTTOM SWITCH [M]
S4 RSH1A045-1A OPEN SWITCH [M]
S5 K0L1BA000065 CHANGE SWITCH [M]
S601 EVQ21405RJ CD 1 SWITCH [M]
S602 EVQ21405RJ CD 2 SWITCH [M]
S603 EVQ21405RJ CD 3 SWITCH [M]
S604 EVQ21405RJ CD 4 SWITCH [M]
S605 EVQ21405RJ CD 5 SWITCH [M]
S606 EVQ21405RJ CD PLAY/PAUSE SWITCH [M]
S607 EVQ21405RJ TAPE SWITCH [M]
S608 EVQ21405RJ TUNER SWITCH [M]
S609 EVQ21405RJ TRACK UP SWITCH [M]
S610 EVQ21405RJ TRACK DOWN SWITCH [M]
S611 EVQ21405RJ ALBUM UP SWITCH [M]
S612 EVQ21405RJ ALBUM DOWN SWITCH [M]
S613 EVQ21405RJ SSEQ SWITCH [M]
S614 EVQ21405RJ POWER SWITCH [M]
S615 EVQ21405RJ SURROUND SWITCH [M]
S616 EVQ21405RJ AUX SWITCH [M]
S617 EVQ21405RJ CD CHECK SWITCH [M]
S618 EVQ21405RJ STOP SWITCH [M]
S619 EVQ21405RJ OPEN/CLOSE SWITCH [M]
S620 EVQ21405RJ CD CHANGE SWITCH [M]
S621 EVQ21405RJ REV SWITCH [M]
S622 EVQ21405RJ FWD SWITCH [M]
S623 EVQ21405RJ REC SWITCH [M]
S701 RSH1A048-A REST SWITCH [M]
S971 RSH1A018-3U MODE SWITCH [M]
S972 RSH1A019-2U HALF SWITCH [M]
S973 RSH1A019-2U CR02 SWITCH [M]
S975 RSH1A019-2U RECINH_F SWITCH [M]
S1901 EVQ21405RJ TAPE EJECT SWITCH [M]
CONNECTORS
CN1 K1MN14B00066 14P FFC CONNECTOR [M]
CN101 K1KA10A00263 10P CONNECTOR [M]
CN301 K1KB13B00017 13P CONNECTOR [M]
CN302 K1KB07A00018 7P CONNECTOR [M]
CN303 K1KA02A00008 2P CONNECTOR (FAN) [M]
CN304 K1KA08B00255 8P CONNECTOR [M]
CN305 K1MN14C00004 14P FFC CONNECTOR [M]
CN306 K1MN17C00002 17P FFC CONNECTOR [M]
CN308 K1MN17A00040 17P FFC CONNECTOR [M]
CN309 K1MN21A00031 21P CONNECTOR [M]
CN504 K1KB08A00100 8P CONNECTOR [M]
CN505 K1KB07A00016 7P CONNECTOR [M]
CN506 RJT119W06V 6P CONNECTOR [M]
CN603A K1KA09B00096 9P CONNECTOR [M]
CN606 K1MN17B00087 17P CONNECTOR [M]
CN701 RJS2A8616 16P FPC CONNECTOR [M]
CN702 RJS2A7717 17P FFC CONNECTOR [M]
CN1305 K1MN21B00010 21P FFC CONNECTOR [M]
CP501 K1KA13A00100 13P CONNECTOR [M]
CP502 K1KA07A00082 7P CONNECTOR [M]
CP1301 K1MN05A00019 5P CONNECTOR [M]
CP1902 K1KA09B00058 9P CONNECTOR [M]
CS971 RJU071H09M1 9P CONNECTOR [M]
COILS & TRANSFORMERS
L203 J0JBC0000019 CHIP INDUCTOR [M]
L300 G0C3R3JA0027 COIL [M]
L301 G0A200D00002 RF CHOKE COIL [M]
L503 G0B371HA0005 LINE FILTER [M]
115
SA-PM31P / SA-PM31PC
