Ref.
No.
Part No. Part Name & Description Remarks
L600 J0JBC0000019 CHIP INDUCTOR [M]
L601 J0JBC0000019 CHIP INDUCTOR [M]
L602 G0C100JA0030 INDUCTOR [M]
L603 G0C101JA0027 COIL [M]
L604 G0C3R3JA0027 COIL [M]
L1301 7L1A62N BIAS OCS COIL [M]
L1302 RLQB470JTD-D RF CHOKE COIL [M]
T501 G4C6BDD00003 MAIN TRANSFORMER [M]
T502 G4C2AAD00004 SUB TRANSFORMER [M]
COMPONENT COMBINATIONS
Z301 ENG06810QF TUNER PACK [M]
Z501 ERZVA5Z471 ZENER [M]
Z601 B3RAB0000040 REMOTE SENSOR [M]
RELAY
RL501 K6B1ADA00011 RELAY [M]
OSCILLATORS
X301 H2A100500006 10MHZ RESONATOR [M]
X302 RSXD32K7S02 CRYSTAL OSCILLATOR [M]
X701 RSXC16M9S04 CRYSTAL [M]
DISPLAY TUBE
FL600 A2BB00000131 FL DISPLAY [M]
FUSE
F1 K5D202APA008 FUSE [M]
FUSE HOLDERS
FC1 EYF52BCY FUSE CLIP [M]
FC2 EYF52BCY FUSE CLIP [M]
FUSE PROTECTORS
FP501 K5G402A00025 FUSE PROTECTOR [M]
FP502 K5G102A00023 FUSE PROTECTOR [M]
HOLDERS
H503 K1YF06000002 6P WIRE HOLDER [M]
H601A RMR0312 3P CABLE HOLDER [M]
H601B RMR0312 3P CABLE HOLDER [M]
H603B RMR0318 9P WIRE HOLDER [M]
H606 RMR0316 7P WIRE HOLDER [M]
EARTH TERMINAL
E501 SNE1004-2 EARTH TERMINAL [M]
JACKS
JK301 K4BC04B00060 JK RED/BLACK SPEAKER [M]
JK302 K4BC04B00059 JK BLUE/HOAR SPEAKER [M]
JK303 K4BK02B00007 JK AUX-IN [M]
JK501 K2AB2B000002 JK AC INLET [M]
JK600 K2HC103B0049 JK HEADPHONE [M]
CHIP JUMPERS
WA100 ERJ3GEY0R00V CHIP JUMPER [M]
WA101 ERJ3GEY0R00V CHIP JUMPER [M]
WA102 ERJ3GEY0R00V CHIP JUMPER [M]
WA103 ERJ3GEY0R00V CHIP JUMPER [M]
WA104 ERJ3GEY0R00V CHIP JUMPER [M]
WA105 ERJ3GEY0R00V CHIP JUMPER [M]
Ref.
No.
Part No. Part Name & Description Remarks
WA106 ERJ3GEY0R00V CHIP JUMPER [M]
WA107 ERJ3GEY0R00V CHIP JUMPER [M]
WA108 ERJ3GEY0R00V CHIP JUMPER [M]
WA110 ERJ3GEY0R00V CHIP JUMPER [M]
WA111 ERJ3GEY0R00V CHIP JUMPER [M]
WA112 ERJ3GEY0R00V CHIP JUMPER [M]
WA113 ERJ3GEY0R00V CHIP JUMPER [M]
WA114 ERJ3GEY0R00V CHIP JUMPER [M]
WA115 ERJ3GEY0R00V CHIP JUMPER [M]
WA116 ERJ3GEY0R00V CHIP JUMPER [M]
WA117 ERJ3GEY0R00V CHIP JUMPER [M]
WA118 ERJ3GEY0R00V CHIP JUMPER [M]
WA119 ERJ3GEY0R00V CHIP JUMPER [M]
WA120 ERJ3GEY0R00V CHIP JUMPER [M]
WA121 ERJ3GEY0R00V CHIP JUMPER [M]
WA122 ERJ3GEY0R00V CHIP JUMPER [M]
WA123 ERJ3GEY0R00V CHIP JUMPER [M]
WA214 ERJ3GEY0R00V CHIP JUMPER [M]
WA414 ERJ3GEY0R00V CHIP JUMPER [M]
WA615 ERJ3GEY0R00V CHIP JUMPER [M]
WA616 ERJ3GEY0R00V CHIP JUMPER [M]
WB201 ERJ8GEY0R00V CHIP JUMPER [M]
WB202 ERJ8GEY0R00V CHIP JUMPER [M]
WB203 ERJ8GEY0R00V CHIP JUMPER [M]
WIRES
WR1308A RWJ0102110SS 2P (MTR WIRE) [M]
WR1903 RWJ0102050KR 2P (MOTOR WIRE) [M]
RESISTORS
R201 D0GB181JA007 180 1/16W [M]
R209 ERJ3GEYJ103V 10K 1/16W [M]
R211 D0GB182JA007 1.8K 1/16W [M]
R214 ERJ3GEYJ103V 10K 1/16W [M]
R218 D0GB392JA041 3.9K 1/16W [M]
R219 D0GB391JA041 390 1/16W [M]
R220 D0GB272JA041 2.7K 1/16W [M]
R221 D0GB123JA007 12K 1/16W [M]
R222 ERJ3GEYJ102V 1K 1/16W [M]
R224 D0GB392JA041 3.9K 1/16W [M]
R230 D0AF100JA039 10 1/4W [M]
R231 D0AF100JA039 10 1/4W [M]
R271 ERJ6GEYJ394V 390K 1/10W [M]
R272 ERJ6GEYJ272V 2.7K 1/10W [M]
R273 ERJ3GEYJ102V 1K 1/16W [M]
R274 ERJ3GEYJ102V 1K 1/16W [M]
R275 D0GB182JA007 1.8K 1/16W [M]
R276 D0GB392JA041 3.9K 1/16W [M]
R301 D0GB472JA041 4.7K 1/16W [M]
R306 ERJ3GEYJ103V 10K 1/16W [M]
R307 D0GB101JA007 100 1/16W [M]
R308 D0GB101JA007 100 1/16W [M]
R309 ERJ3GEYJ103V 10K 1/16W [M]
R310 ERJ3GEYJ103V 10K 1/16W [M]
R312 D0GB222JA041 2.2K 1/16W [M]
R313 D0GB101JA007 100 1/16W [M]
R314 D0GB101JA007 100 1/16W [M]
R315 D0GB101JA007 100 1/16W [M]
R316 D0GB101JA007 100 1/16W [M]
R317 D0GB101JA007 100 1/16W [M]
R318 D0GB101JA007 100 1/16W [M]
R319 D0GB101JA007 100 1/16W [M]
R320 D0GB101JA007 100 1/16W [M]
R321 D0GB101JA007 100 1/16W [M]
R322 D0GB101JA007 100 1/16W [M]
R323 D0GB472JA041 4.7K 1/16W [M]
R324 D0GB472JA041 4.7K 1/16W [M]
R325 D0GB473JA041 47K 1/16W [M]
R326 D0GB472JA041 4.7K 1/16W [M]
R327 D0GB472JA041 4.7K 1/16W [M]
