Panasonic SA-PT560E - Component Parts List

25.1. Component Parts List
Ref.
No.
Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 L6FAJCCH0007 FAN MOTOR [M]
2 REEX0813 22P FFC CABLE (MN-SCART) [M]
3 REEX0814 50P FFC CABLE (MN-DVD) [M]
4 REEX0815 17P FFC CABLE (MN-DAMP) [M]
5 REEX0817 7P FFC CABLE (OPU-DVD) [M]
6 REEX0820 17P FFC CABLE (PAN-MN) [M]
7 REEX0821 14P FFC CABLE (IPOD-PWRSUPP) [M]
8 REEX0822 28P FFC CABLE (PWRSUPP-MN) [M]
9 REEX0823 4P FFC CABLE (PWRBUT-MN) [M]
10 RGUX0744-K SUBWOOFER BUTTON [M]
E/EB/EG
-K
10 RGUX0744-S SUBWOOFER BUTTON [M]
E/EG-S
11 REXX0636-J 5P USB WIRE (USB-DVD) [M]
12 REXX0640-J BLACK WIRE (AC-SMPS) [M]
13 REXX0641-J RED WIRE (AC-SMPS) [M]
14 REXX0651 8P FLAT WIRE (SMPS-DAMP) [M]
15 RGB0164-S PANASONIC BADGE [M]
16 RGKX0443-K DVD LID [M]
17 RGKX0489A-S FRONT ORNAMENT [M]
18 VHD1224-1 SCREW [M]
19 RYPX0258-S1 CRADLE UNIT [M]
E/EG-S
19 RYPX0258-K1 CRADLE UNIT [M]
E/EB/EG
-K
20 RGLX0160-Q LIGHTING CHIP [M]
21 RGPX0334-K3 FRONT PANEL [M]
E/EG-K
21 RGPX0334-S2 FRONT PANEL [M]
E/EG-S
21 RGPX0334A-K3 FRONT PANEL [M] EB-
K
22 RGPX0335C-K1 CRADLE CHASSIS [M]
E/EB/EG
-K
22 RGPX0335C-S1 CRADLE CHASSIS [M]
E/EG-S
23 RGRX0067B-A REAR PANEL [M]
E/EG-
K/S
23 RGRX0067B-B REAR PANEL [M] EB-
K
24 RGUX0741-K1 OPEN CLOSE BUTTON [M]
E/EB/EG
-K
24 RGUX0741-S1 OPEN CLOSE BUTTON [M]
E/EG-S
25 RGUX0742-K POWER BUTTON [M]
E/EB/EG
-K
25 RGUX0742-S POWER BUTTON [M]
E/EG-S
26 RXXX0085-1J HEATSINK UNIT A [M]
27 RGUX0745-K OPERATION BUTTON [M]
E/EB/EG
-K
27 RGUX0745-S OPERATION BUTTON [M]
E/EG-S
28 RGWX0104-K VOLUME KNOB [M]
E/EB/EG
-K
28 RGWX0104-S VOLUME KNOB [M]
E/EG-S
29 RHD26046 SCREW [M]
30 RHD30007-1SJ SCREW [M]
E/EG-S
30 RHD30007-K2J SCREW [M]
E/EB/EG
-K
31 RHD30090-1 SCREW [M]
32 RHD30111-3 SCREW [M]
33 RHD30119-S SCREW [M]
Ref.
No.
Part No. Part Name & Description Remarks
34 ENG07824QRF TUNER PACK [M]
35 RHDX03001 SCREW [M]
36 RKA0059-K LEG FELT [M]
37 RKWX0279-Q FL WINDOW [M]
38 RMAX0118-1 PCB BRACKET [M]
39 RMAX0129 PANEL ANGLE [M]
40 RMAX0130 DVD LID HOLDER [M]
41 RMAX0131 MAIN PCB BRACKET B [M]
42 RMAX0132 MECHA CHASSIS [M]
43 RMBX0075 DOOR SPRING [M]
44 RMC0465 TR SPRING [M]
45 RMCX0042 EARTH SPRING [M]
46 RMCX0055 SPRING PLATE [M]
47 RMCX0057 SPRING (FOR USB) [M]
48 RMGX0050 CRADLE RUBBER [M]
49 RMNX0207 SMPS PCB INSULATOR ( TOP ) [M]
50 RXQX0077 FL SHIELD PLATE UNIT [M]
51 RMNX0254 USB BRACKET [M]
52 RMNX0260 FL HOLDER [M]
53 RMNX0282A AC-IN PC SHEET A [M]
54 RMNX0282B AC-IN PC SHEET B [M]
55 RXXX0104 HEATSINK UNIT B [M]
56 RQXQ0041 CUSHION ASS´Y [M]
57 RMNX0286 HDMI PC SHEET [M]
58 RMQX0233-K FAN COVER [M]
59 RMR0502A-W PCB SUPPORT [M]
60 RXXX0105 HEATSINK UNIT C [M]
61 RMVX0117-K CONNECTOR COVER [M]
E/EB/EG
-K
61 RMVX0117-S CONNECTOR COVER [M]
E/EG-S
62 RMX0302 DAMPER RUBBER [M]
63 RMYX0191 HEATSINK EXTRUSSION [M]
64 RMZX0038 IC INSULATOR [M]
65 RSCX0188 SHIELD [M]
66 RKMX0141-K TOP CABINET [M]
E/EB/EG
-K
66 RKMX0141-S TOP CABINET [M]
E/EG-S
67 RSCX0191 SHIELD [M]
68 RMKX0144 BOTTOM CHASSIS [M]
69 XSN3+4FJ SCREW [M]
70 XTB3+10JFJ SCREW [M]
71 XTB3+8JFJ SCREW [M]
72 XTW3+8TFJ SCREW [M]
73 REXX0653-J 13P WIRE (MN-PWRSUPP) [M]
74 REXX0639-J 11P WIRE (SMPS-PWRSUPP) [M]
75 REEX0811 14P FFC WIRE (MN-WIRELESS) [M]
76 RMKX0127-K1 TRANSMITTER CHASSIS [M]
77 RMVX0109-K1 TRANSMITTER COVER [M]
PRINTED CIRCUIT BOARDS
PCB1 REPX0620A DVD MODULE P.C.B [M]
(RTL)
PCB2 REPX0621D D-AMP P.C.B [M]
(RTL)
PCB3 REPX0622B SMPS / AC INLET P.C.B [M]
(RTL)
PCB4 REPX0627A MAIN/SCART/POWER
SUPPLY/WIRELESS ADAPTOR P.C.B
[M]
(RTL)
EG
REPX0627B MAIN/SCART/POWER
SUPPLY/WIRELESS ADAPTOR P.C.B
[M]
(RTL)
EB
REPX0627C MAIN/SCART/POWER
SUPPLY/WIRELESS ADAPTOR P.C.B
[M]
(RTL) E
PCB5 REPX0655A PANEL P.C.B [M]
(RTL)
PCB5 REPX0655A POWER BUTTON P.C.B [M]
(RTL)
PCB5 REPX0655A USB P.C.B [M]
(RTL)
144
SA-PT560E / SA-PT560EB / SA-PT560EG
